MQAM信号调制方式盲识别

张路平; 王建新

doi:10.3724/SP.J.1146.2010.00472

MQAM信号调制方式盲识别

doi: 10.3724/SP.J.1146.2010.00472

张路平^{* 王建新,},
王建新

计量
- 文章访问数: 3943
- HTML全文浏览量: 154
- PDF下载量: 1091
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-14
- 修回日期: 2010-09-16
- 刊出日期: 2011-02-19

Blind Modulation Recognition Algorithm for MQAM Signals

Zhang Lu-Ping^{* 王建新
,},
Wang Jian-Xin

摘要

摘要: 该文提出了一种MQAM信号调试方式的盲识别算法。算法首先通过信号频谱粗略估计信号载频和带宽，从而进行下变频和低通滤波。然后通过信号包络平方的频谱估算出波特率，结合符号定时完成信号的波特率采样。最终计算MQAM信号矢量图中最小环带的方差，完成调制方式的识别。该MQAM信号调制识别算法无需载频和波特率等先验信息，对载波残余不敏感，没有复杂的迭代过程，可以应用于实际信号的调制识别。仿真表明信噪比在16 dB，码元数目为2400时，对5种QAM信号的识别率达到99%以上，证明了其有效性。
- 信号处理 /
- 调制识别 /
- MQAM /
- 矢量图 /
- 方差
Abstract: A blind modulation recognition algorithm for MQAM signals is proposed. The method firstly estimates the signal carrier frequency and bandwidth from its spectrum to complete the frequency conversion and the low-pass filtering. Then the baud rate is estimated by calculating the frequency spectrum of the square envelope, and the baud rate sampling is done according the symbol timing. Finally the modulation type is identified by comparing the variance of sequences in the minimum ring of vectogram. It does not require prior information about carrier frequency and baud rate, and is not sensitive to the carrier offset. Moreover, there is no complex iterative process. So it is suitable for signal recognition of practical applications. Computer simulations show that the correct recognition probability is larger than 99% if SNR is greater than 16dB and using 2400 symbols. It verifies the validity of the algorithm.
- Signal processing /
- Modulation recognition /
- MQAM /
- Vectogram /
- Variance

HTML全文

参考文献(1)

[1] Dobre O A, Abdi A, and Bar-Ness Y, et al.. Survey of automatic modulation classification techniques: classical approaches and new trends[J].IET Commun.2007, 1(2):137-156 [2] Kam-Tim W and Chi-Wah K. Clustering based distribution fitting algorithm for Automatic Modulation Recognition. IEEE Symposium on Computers and Communications, Aveiro, Portugal, 2007: 13-18. [3] 叶健, 吴月娴, 葛临东. 基于高效自适应聚类算法的调制识别研究[J].计算机工程与设计.2007, 28(3):506-508 Ye J, Wu Y X, and Ge L D. Study on efficient adaptive clustering algorithm based modulation identification. Computer Engineering and Design, 2007, 28(3): 506-508. [4] 田玉双，王曰海，李式巨等. 存在定时误差的MQAM信号调制方式识别. 江南大学学报(自然科学版), 2008, 7(2): 179-182. Tian Y S, Wang Y H, and Li S J, et al.. Modulation classification for timing-error MQAM signal. Journal of Jiangnan University(Natural Science Edition), 2008, 7(2): 179-182. [5] 程汉文，朱雷，吴乐南. 基于累计量的干扰信号调制识别算法[J].电子与信息学报.2009, 31(7):1741-1745浏览 Chen H W, Zhu L, and Wu L N. Modulation classification algorithm for jamming signal based on cumulant[J].Journal of Electronics Information Technology.2009, 31(7):1741-1745 [6] Liu L K and Xu J D. A novel Modulation classification method based on high order cumulants. International Conference on Wireless Communications, Networking and Mobile Computing, Wuhan, China, 2006: 1-5. [7] Liu Y and Zhang Z P. High order QAM signals recognition based on layered modulation. International Conference on Communications, Circuits and Systems, Milpitas, USA, 2009: 73-76. [8] 黄英,雷菁. 卫星通信中调制识别算法研究. 系统工程与电子技术, 2009, 31(6): 1303-1306. Huang Y and Lei J. Research on recognition of modulation signals in satellite communication. Systems Engineering and Electronics, 2009, 31(6): 1303-1306. [9] Shi Q H, Gong Y, and Guan Y L. Asynchronous classification of high-order QAMs. IEEE Wireless Communications and Networking Conference, Las Vegas, USA, 2008: 1188-1193. [10] 冯祥, 李建东. 基于高阶循环累积量的SQAM信号调制识别算法[J].电子与信息学报.2007, 29(1):125-128浏览 Feng X and Li J D. Robust modulation classification algorithm based on higher-order cyclic cumulants for SQAM signals with frequency offset[J].Journal of Electronics Information Technology.2007, 29(1):125-128 [11] 褚衍杰,胡年福，巢凯今等. 通带MQAM信号调制方式识别方法. 西安电子科技大学学报(自然科学版), 2008, 35(5): 932-937. Chu Y J, Hu N F, and Chao K J, et al.. Modulation recognition of MQAM signals in the passband. Journal of Xidian University, 2008, 35(5): 932-937. [12] 奚家熹,王宗欣. 基于Hilbert变换的MQAM信号调制体制识别[J].通信学报.2007, 28(6):1-6 Xi J X and Wang Z X. MQAM modulation scheme recognition using Hilbert transform. Journal on Communications, 2007, 28(6): 1-6. [13] Xu Z N and Bai W L. A novel blind recognition algorithm for modulated M-QAM signals. International conference on communications and mobile computing, Kunming, China, 2009: 461-465.
