MIMO-SAR中虚拟孔径相位校正与子带合成方法研究

周高杯; 宋红军; 邓云凯

doi:10.3724/SP.J.1146.2010.00435

MIMO-SAR中虚拟孔径相位校正与子带合成方法研究

doi: 10.3724/SP.J.1146.2010.00435

周高杯^{*①② 宋红军,},
宋红军,
邓云凯

计量
- 文章访问数: 3647
- HTML全文浏览量: 148
- PDF下载量: 764
- 被引次数: 0
出版历程
- 收稿日期: 2010-04-30
- 修回日期: 2010-09-06
- 刊出日期: 2011-02-19

Investigation of Virtual Aperture Phase Correction and Sub Band Synthesis Algorithms in MIMO-SAR

Zhou Gao-Bei^{*①② 宋红军
,},
Song Hong-Jun,
Deng Yun-Kai

摘要

摘要: 该文对单发射多接收(SIMO)和多发射多接收(MIMO)系统进行了研究，对多个孔径天线依次发射，多个孔径同时接收和多个孔径天线同时发射接收等工作方式进行了理论推导，通过采用虚拟孔径相位校正的方法，实现单发多收信号叠加成像。对多个频率同时发射方式，通过采用子带合成和虚拟孔径相位校正的方法，实现多个接收信号的叠加。并对虚拟孔径相位校正的方法进行了点目标仿真。为SAR新体制应用提供了潜在的处理方法。
- MIMO-SAR /
- MIMO /
- SIMO /
- 虚拟孔径 /
- 子带合成
Abstract: This paper investigates on SAR system that is constituted from Single-Input Multiple-Output (SIMO) or Multiple-Input Multiple-Output (MIMO), and researches the working mode of transmitting one by one or transmitting in same time with multiple transmitters and multiple receivers. Through virtual aperture phase correction, SIMO signal iterations and image algorithms with multiple receivers are performed. Through sub band synthesis and virtual aperture phase correction, MIMO signal iterations and image algorithms are processed with the similar ways; and some simulations of virtual aperture phase correction with three point objects images are provided. The algorithms will be potential to new MIMO-SAR system.
- MIMO-SAR /
- MIMO /
- SIMO /
- Virtual aperture /
- Sub band synthesis

HTML全文

参考文献(1)

Ender J H G and Klare J. System architectures and algorithms for radar Imaging by MIMO-SAR [C]. IEEE Radar Conference, Pasadena, CA, USA, 2009: 1-6.[2]Klare J. Digital beamforming for a 3D MIMO SAR improvements through frequency waveform diversity[C]. IGRASS, Boston, MA, USA, 2008: 17-20.[3]李海英. 超宽带信号波形及其合成孔径雷达成像研究. [博士论文], 北京：中国科学院电子学研究所，2002.[4]Li Hai-ying. Ultra-wide band signal wave and investigation of SAR image. [Ph.D. dissertation], Beijing: Institute of Electrics, Chinese Academy of Science, 2002.[5]Cumming I G and Wong F H. Digital processing of synthetic aperture radar data: algorithms and implementation. Artech House, INC, 2005: 158-172.[6]Li Jian, Zheng Xia-yu, and Stoicat P. MIMO SAR imaging: signal synthesis and receiver design[C]. CAMPSAP, St. Thomas, VI, 2007: 89-92.[7]Li Hong-bin and Himed B. Transmit subaperturing for MIMO radars with co-located antennas[J].IEEE Journal of Selected Topics in Signal Processing.2010, 4(1):55-65[8]Krieger G, Gebert N, Younis M, and Moreira A. Advanced synthetic aperture radar based on digital beamforming and waveform diversity[C]. RADAR '08. Rome, 2008: 1-6.[9]Correll B. Efficient spotlight SAR MIMO linear collection configurations[J].IEEE Journal of Selected Topics in Signal Processing.2010, 4(1):33-39[10]Wang Wen-qin, Peng qiong, and Cai Jing-ye. Diversified MIMO SAR waveform analysis and generation[C]. APSAR, Xian, Shanxi 2009: 270-273.[11]Fuhrmann D R, Browning J P, and Rangaswamy M. Signaling strategies for the hybrid MIMO phased-array radar[J].IEEE Journal of Selected Topics in Signal Processing.2010, 4(1):66-77[12]Junghyo Kim and Wiesbeck W. Investigation of a new multifunctional high performance SAR system concept exploiting MIMO technology[C]. IGARSS, Boston, MA, 2008: II-221-II-224.
