伪随机序列编码脉冲信号在探地雷达中的应用研究

张群英; 方广有

doi:10.3724/SP.J.1146.2010.00356

伪随机序列编码脉冲信号在探地雷达中的应用研究

doi: 10.3724/SP.J.1146.2010.00356

张群英^{* 方广有,},
方广有

计量
- 文章访问数: 3743
- HTML全文浏览量: 171
- PDF下载量: 1012
- 被引次数: 0
出版历程
- 收稿日期: 2010-04-07
- 修回日期: 2010-07-15
- 刊出日期: 2011-02-19

The Study of Pseudo Random Sequences Application to GPR

Zhang Qun-Ying^{* 方广有
,},
Fang Guang-You

摘要

摘要: 探测深度是探地雷达最为重要的指标之一，在一定分辨率情况下如何增加探测深度一直是国内外研究的热点问题。该文对伪随机序列编码脉冲信号在探地雷达中的应用进行了研究，分析了伪随机序列编码脉冲信号的特点以及探地雷达对发射信号的应用需求，介绍了一个采用m序列二相脉冲调制的探地雷达实验系统，给出了该系统的测试和实验结果并对实验结果进行了理论分析，实验结果与理论分析十分吻合。分析与实验结果表明：在同样条件下，伪随机序列编码脉冲探地雷达较传统的Impulse探地雷达可以实现更大的探测深度，可以满足考古、地质勘察等深层探测应用的需求。
- 探地雷达 /
- 冲激雷达 /
- 伪随机序列 /
- 非周期自相关函数 /
- 冲激函数
Abstract: The sounding depth is one of the most important parameter of GPR (Ground Penetrating Radar), how to expand detectable range under a given resolution is a concern issue in the field of GPR all over the world. The application of Pseudo Random Binary Sequence (PRBS) to GPR is studied in this paper. The advantages of PRBS and the demands of GPR are analyzed. A GPR experiment system adopting m-sequence is described. Some experimental data of this system and the theoretical analysis are presented. The experiments results are very coincide with theoretical analysis. This PRBS GPR can achieve deeper detectable range than Impulse GPR under the same parameters is proved with the result of analysis and experiment, and it can meet the demands of the archaeology and geologys deep sounding.
- Ground Penetrating Radar (GPR) /
- Impulse GPR /
- Pseudo Random Binary Sequence (PRBS) /
- Non- period correlation function /
- Impulse function

HTML全文

参考文献(1)

Daniels D J. Ground Penetrating Radar. The Institute of Engineer Engineers, London, United Kingdom, Michael Faraday House, 2004: 3-4.[2]Charlotte Corbel, Svein-Erik Hamran, and Richard Ney, et al.. The WISDOM UHF GPR on ExoMars mission. 11th International Conference on Ground Penetrating Radar, Columbus Ohio, USA, June 19-22, 2006: 15-20.[3]Aftanas Michal. Imaging of the building contours with through the wall UWB radar system. Radio Engineering, 2009, 18(3): 258-264.[4]Kazunori Takahashi and Motoyuki Sato. A hand-held dual- sensor system using impulse GPR for demining. Proceedings of the 2008 IEEE International Conference on Ultra- Wideband (ICUWB2008), Germany, September 10-12, 2008: 157-160.[5]Andreas Loizos and Christina Plati. Ground penetrating radar: a smart sensor for the evaluation of the railway trackbed. Instrumentation and Measurement Technology ConferenceIMTC 2007Warsaw, Poland, May 1-3, 2007: 1-6.[6]Zetik R, Sachs J, and Thom. R S[J].UWB short-range radar sensingThe architecture of a baseband, pseudo-noise UWB radar sensor. IEEE Instrumentation Measurement Magazine.2007, 4:39-45[7]Sachs J and Badstbner A. High resolution non-destructive testing in civil engineering by ultra-wideband pseudo-noise approaches. Proceedings of the 2008 IEEE International Conference on Ultra- Wideband (ICUWB2008), Germany, September 10-12, 2008: 137-140.[8]Yoshiyuki Tomizawa and Ikuo Arai. Coded pulse signal subsurface radar. Electronics and Communications in Japan, 2002, Part 1, 85(2): 8-16.[9]Ana Vazquez Alejos and Dawood Muhammad, et al.. Ground Penetration Radar using Golay Sequence. 2007 IEEE Region 5 Technical Conference, Fayetteville, AR, April 20-21, 2007: 318-321.[10]Ing. Michal Aftanas. Through wall imaging using M-sequence UWB radar system. [Ph.D. disertation], Technical University at Kosice, 2007.[11]Bianchi C, Sciacca U, and Zirizzotti A, et al.. Signal processing techniques for phase-coded HF-VHF radars. Annals of Geophysics, 2003, 46(4): 697-705.[12]张群英，方广有，尹肖飞. 一种伪随机序列在探地雷达应用中回波数据预处理方法. 中国专利, 200810227477.8, 2008. Zhang Qun-ying, Fang Guang-you, and Yin Xiao-fei. An Pre-processing algorithm of Pesduo random sequences echo in GPR. China Patent 200810227477.8, 2008.[13]Ming Yan, Mao Tian, and Lu Gan, et al.. Impulse ground penetrating radar hardware system design, Proceedings of 6th Intermational Coference on ITS Teleconnunuications, Taiwan, June 26-30, 2006: 1244-1247.[14]Aftanas M, Rovnakova J, and Riskova M, et al.. An analysis of 2D target positioning accuracy for M-sequence UWB radar system under ideal conditions. Proceedings of 7th International Conference Radioelektronika, Brno, Czech Republic, Apr. 2007: 189-194.
