基于广义旁瓣相消器的滤波器组旁瓣干扰抑制

李涛; 李国林; 廖辉荣

doi:10.3724/SP.J.1146.2010.00280

基于广义旁瓣相消器的滤波器组旁瓣干扰抑制

doi: 10.3724/SP.J.1146.2010.00280

李涛^{* 李国林廖辉荣,},
李国林,
廖辉荣

计量
- 文章访问数: 3730
- HTML全文浏览量: 109
- PDF下载量: 1598
- 被引次数: 0
出版历程
- 收稿日期: 2010-03-23
- 修回日期: 2010-09-06
- 刊出日期: 2011-01-19

Side-lobe Inteference Suppression for Filter Banks Based on GSC

Li Tao^{* 李国林廖辉荣
,},
Li Guo-Lin,
Liao Hui-Rong

摘要

摘要: 传统滤波器组为降低旁瓣，需要提高滤波器阶数。该文将广义旁瓣相消的思想运用于滤波器组的旁瓣干扰抑制，在滤波器通带外的干扰信号频率处自适应形成零点。基于LMS算法，该文提出了基于自适应旁瓣相消器的滤波器组旁瓣干扰抑制算法，给出了算法的矩阵形式。通过限制系数长度，旁瓣相消器仅仅对消旁瓣大功率干扰信号，而对带内有用信号的影响很小，其作用相当于用一个低阶滤波器实现一个高阶数滤波器的功能，当信号功率较之干扰功率很小时尤其有用。仿真结果显示算法具有良好的旁瓣干扰抑制性能，较之高阶滤波器组大大减少了计算量。
- 电子战 /
- 干扰抑制 /
- 广义旁瓣相消器 /
- LMS算法 /
- 滤波器组
Abstract: In order to improve side-lobe performance, traditional filter banks have to increase order number. In this paper Generalized Side-Lobe Canceller (GSC) is introduced to cancel strong jamming signals from side-lobes of filter banks, which can place zeros at stop band adaptively. The matrix form of this adaptive algorithm is provided, based on LMS algorithm. The length of the canceller coefficients is confined so the canceller just cancels strong jamming signals, with little influence on pass band signals. This method realizes the function of high-order filter banks through low-order filter banks and especially suited for weak signal detection. The simulation analysis indicates that it reduces computation quantity relative to high-order filter banks but maintains the same performance.
- Electronic warfare /
- Interference suppression /
- Generalized Side-lobe Canceller (GSC) /
- LMS algorithm /
- Filter banks

HTML全文

参考文献(1)

黄翔东, 王兆华. 两通道完全重构全相位FIR滤波器组设计[J]. 天津大学学报, 2006, 39(12): 1504-1508.Huang Xiang-dong and Wang Zhao-hua. Design of two-channel perfect reconstruction all-phase FIR filter bank[J]. Journal of Tianjin University, 2006, 39(12): 1504-1508.[2]何改平. 矩阵共轭镜像滤波器组的设计[J]. 西安邮电学院学报, 2009, 14(3): 61-64.[3]He Gai-ping. Construction of matrix conjugate quadrature filters[J]. Journal of XiAn University of Post and Telecom,　2009, 14(3): 61-64.[4]洪淑月. 近似重构正交镜像滤波器组的设计[J]. 浙江师范大学学报(自然科学版), 2006, 29(3): 277-281.Hong Shu-yue. Design of QMF with near-perfect reconstruction[J]. Journal of ZheJiang Normal University (Nature Science), 2006, 29(3): 277-281.[5]Saramki T and Bregovi? R. An efficient approach for designing nearly perfect reconstruction cosine modulated and modified DFT filter banks. Proceedings of the IEEE International Conference on Acoustics, Speech, and Signal Proceeding, Salt Lake City, 2001. [5] 张子敬. 焦李成. 余弦调制滤波器组的原型滤波器设计[J]. 电子与信息学报, 2002, 24(3): 308-313.Zhang Zi-jing and Jiao Li-cheng. Design of prototype filter for cosine-modulated filter banks[J].Journal of Electronics Information Technology.2002, 24(3):308-313[6]刘泽民, 李学斌. M带均匀最大抽取滤波器组[J].电子与信息学报.2003, 25(3):326-329浏览Liu Ze-min and Li Xue-bin. M-band uniform maximally decimated filter banks[J].Journal of Electronics Information Technology.2003, 25(3):326-329[7]Xie X M, Shi G M, and Chen X Y. Optimal prototype filters for near perfect reconstruction cosine modulated filter banks[J].Lecture Notes in Computer Science.2005, 3802:851-856[8]朱建东, 王小龙. 基于余弦调制的二维LP-NPR 滤波器组设计[J]. 计算机工程与应用, 2009, 45(3): 141-144.Zhu Jian-dong and Wang Xiao-long. Design for two dimensional LP-NPR filter banks based on cosine modulation[J]. Computer Engineering and Application, 2009, 45(3): 141-144.[9]Griffths L J and Jim C W. An alternative approach to linearly constrained adaptive beam forming[J].IEEE Transactions on Antennas and Propagation.1982, 30(1):27-34[10]余岚, 杨春兰. 基于数字波束形成技术的空间干扰抑制算法研究[J]. 舰船电子工程, 2009, 29(10): 87-89.Yu Lan and Yang Chun-lan. Research on spatial interference suppression algorithm based on digital beamforming technology[J]. Ship Electronic Engineering, 2009, 29(10): 87-89.
