耦合腔行波管电参量对降压收集极特性的影响

张英辉; 罗积润; 郭炜; 朱敏

doi:10.3724/SP.J.1146.2010.00182

耦合腔行波管电参量对降压收集极特性的影响

doi: 10.3724/SP.J.1146.2010.00182

张英辉^{*①② 罗积润,},
罗积润,
郭炜,
朱敏

计量
- 文章访问数: 3490
- HTML全文浏览量: 101
- PDF下载量: 677
- 被引次数: 0
出版历程
- 收稿日期: 2010-03-01
- 修回日期: 2010-05-20
- 刊出日期: 2011-01-19

Influence of the Electrical Parameters on Multistage Depressed Collector Characteristics in a Coupled Cavity TWT

Zhang Ying-Hui^{*①② 罗积润
,},
Luo Ji-Run,
Guo Wei,
Zhu Min

摘要

摘要: 该文基于Orprogr软件，在X波段模拟设计出耦合腔行波管的期待电性能，并利用互作用后的电子注为入口条件，优化设计出收集效率大于71.5%、电子注着陆相对均匀的三级降压收集极。在上述条件下，讨论了电子进入收集极层流性(速度比)、电极形状、电极电压以及收集极内电场分布对电子运动的影响，从物理上给出了电子注在收集极表面着陆特点的详细分析。
- 耦合腔行波管 /
- 模拟设计 /
- 降压收集极
Abstract: In this article, based on a coupled cavity TWT design software, Orprogr code, the simulation design of a X band coupled cavity TWT is performed for realizing the expected electric characteristics. Under the condition of the above-mentioned design results, a depressed collector is designed with the minimum collector efficiency of 71.5% and the electron beam may relatively evenly spreads on the surface of each sub-area of the depressed collector. Then the influence of laminar flow, electrode shape, voltage drop and electrical field on the distribution of the beam is discussed by analyzing the spreading of electron beam on the surface of each sub-area of the depressed collector.
- Coupled cavity TWT /
- Simulation design /
- Depressed collector

HTML全文

参考文献(1)

Keishi Sakamoto, Atsushi Kasugai, and Koji Takahashi, et al.. Achievement of robust high-efficiency 1 MW oscillation in the hard-self-excitation region by a 170 GHz continuous-wave gyrotron[J].Nature Physics.2007, 3(6):411-414[2]Sun Hai-yan, C Jiao hong-qing, and Luo Ji-run. Influence of Reflections of the Output Port on Beam-wave Interaction in Gyrotron Traveling Wave Amplifier[J].Journal of Infrared and Millimeter Waves.2008, 29(18):657-662[3]Ding M Q, Huang M G, Feng J J, Bai GD, and Yan T C. Ion surface modification for space TWT multistage depressed collectors[J].Applied Surface Science.2008, 255(5):2196-2199[4]Liu Ben-tian, Jiao Chong-qing, and Zhang Yan-sheng, et al.. Experimental study of a Ku-band gyrotron backward-wave oscillator with a single stage depressed collector[J].IEEE Transactions on Plasma Science.2007, 35(4):1065-1069[5]李延威, 李建清. 空间行波管收集极的热特性分析[J]. 强激光与粒子束, 2009, 21(3): 399-402.Li Yan-wei and Li Jian-qing. Thermal performance analysis of space traveling wave tube collector[J]. High Power Laser and Particle Beams, 2009, 21(3): 399-402.[6]韩勇, 刘燕文, 丁耀根, 等. 螺旋线行波管慢波系统的综合热分析法[J].电子与信息学报.2009, 31(12):3015-3018浏览Han Yong, Liu Yan-wen, and Ding Yao-gen, et al.. Synthetic analysis method of the heat dissipation capability of slow-wave structure for helix TWT[J].Journal of Electronics Information Technology.2009, 31(12):3015-3018[7]Granastein V L, Parker R K, and Armstrong C M. Vacuum electronics at the dawn of the twenty-first century[J].Proceedings of the IEEE.1999, 87(5):702-716[8]Sharma S M, S Arya, and Kumawat NL, et al.. Carbon coated electrodes for multistage depressed collector of high efficiency helix TWTs[C]. Proceedings of International Conference on Microwave-08, Beijing, 2008: 865-867.[9]郭开周. 行波管研制技术[M]. 北京: 电子工业出版社, 2007: 87.Guo Kai-zhou. Traveling Wave Tube Design[M]. Beijing: Publishing House of Electronics Industry, 2007: 87.[10]Huang Tao, Zhong Quan-hu, and Yang Hai, et al.. Electron optics simulator: a three-dimensional finite-element electron gun and collector design tool[J].IEEE Transactions on Electron Devices.2009, 56(1):140-148[11]刘盛纲. 微波电子学导论[M]. 北京: 国防工业出版社, 1985: 285.Liu Sheng-gang. Introduction to Microwave Electronics[M]. Beijing: National Defense Industry Press, 1985: 285.[12]Antonsen T M. Advances in modeling of vacuum electronic devices[C]. 9th IEEE International Vacuum Electronics Conference Monterey, CA, APR 22-24, 2008: 1-2.
