基于相位线性度的ISAR非平稳目标成像时间选择新算法

彭石宝; 许稼; 向家彬; 彭应宁

doi:10.3724/SP.J.1146.2010.00158

基于相位线性度的ISAR非平稳目标成像时间选择新算法

doi: 10.3724/SP.J.1146.2010.00158

彭石宝^{① 许稼,},
许稼,
向家彬,
彭应宁

基金项目:

国家自然科学基金(60971087)和空装项目(kj05131)资助课题

计量
- 文章访问数: 3807
- HTML全文浏览量: 121
- PDF下载量: 939
- 被引次数: 0
出版历程
- 收稿日期: 2010-02-11
- 修回日期: 2010-06-28
- 刊出日期: 2010-12-19

A Novel ISAR Imaging Time Selection Method for Maneuvering Target Based on Phase Linear Degree

摘要

摘要: 该文针对非平稳旋转目标ISAR成像时间选择问题，提出基于相位线性度准则的成像时间选择新算法。首先详细分析了目标非平稳旋转时散射点的相位特性，提出适合目标成像的运动条件；然后基于目标平均距离像提取两个特显点距离单元信号，共轭相乘去除平动相位，相位解缠并曲线拟合得到转动相位，进而评价不同时间段转动相位的线性度，选择线性度大的时刻为成像时间。最后用仿真和实测数据验证了该方法的有效性。
- 逆合成孔径雷达 /
- 非平稳目标 /
- 成像时间选择 /
- 相位线性度
Abstract: In order to select a suitable time interval to reconstruct a well-focused ISAR image for maneuvering target in long recorded data, a novel method based on Phase Linear Degree (PLD) is proposed in this paper. Firstly, the scatterer phase property is deduced in detail and the imaging time condition is given. Secondly, two prominent range cells are selected based on the Average Range Profile (ARP), and the radial phase is removed by the two range cells conjugate multiplication. Then the rotation phase is curve fitting based on the unwrapping phase. Accordingly, the phase linear degree of the rotation phase is evaluated at the different time interval, and the interval with the highest phase linear degree is selected as the imaging time. Finally, the technique effectiveness is tested by simulated and real data.
- ISAR /
- Maneuvering target /
- Imaging time selection /
- Phase Linear Degree (PLD)

HTML全文

参考文献(1)

Aprile A, Meledandri D, Pellizzeri T M, and Mauri A. Translational rotational motion compensation: a single algorithm for different radar imaging applications [J].IET Signal Processing.2008, 2(3):204-215[2]Munoz-Ferreras J M and Perez-Martinez F. Uniform rotational motion compensation for inverse synthetic aperture radar with non-cooperative targets [J].IET Radar Sonar Navigation.2008, 2(1):25-34[3]Gao Zhao-zhao, Li Ya-chao, and Xing Meng-dao, et al.. ISAR imaging of manoeuvring targets with the range instantaneous chirp rate technique [J].IET Radar Sonar Navigation.2009, 3(5):449-460[4]Rihaczek A W and Hershkowitz S J. Choosing imaging intervals for small ships [C]. SPIE Conference on Radar Processing, 1999, 3810: 139-148.[5]Hajduch G, Le Caillec J M, and Garello R. Airborne high-resolution ISAR imaging of ship targets at sea [J].IEEE Transaction on Aerospace, Electronic and System.2004, 40(1):378-384[6]汪玲, 朱兆达, 朱岱寅. 机载ISAR舰船侧视和俯视成像时间段选择[J].电子与信息学报.2008, 30(12):2835-2839浏览Wang Ling, Zhu Zhao-da, and Zhu Dai-yin. Interval selections for side-view or top-view imaging of ship targets with airborne ISAR [J].Journal of Electronics Information Technology.2008, 30(12):2835-2839[7]Pastina D and Spina C. Slope-based frame selection and scaling technique for ship ISAR imaging [J].IET Signal Processing.2008, 2(3):265-276[8]Martorella M and Berizzi F. Time windowing for highly focused ISAR image reconstruction [J].IEEE Transaction on Aerospace, Electronic and System.2005, 41(3):992-1007[9]Sun Hai-ping, Xing Meng-dao, and Zhou Li-juan. Division of imaging intervals and selection of optimum imaging time for ship ISAR imaging based on measured data [C]. IEEE Radar Conference, China, 2006: 2790-2794.[10]Li J F and Ling H. An algorithm to detect the presence of 3D target motion from ISAR data [J].Multidimensional Systems and Signal Processing.2003, 14(1-3):223-240[11]韩兴斌, 胡卫东, 郁文贤. 基于散射点信号特性的ISAR成像时间选择算法[J]. 信号处理, 2007, 23(5): 705-709.Han Xing-bin, Hu Wei-dong, and Yu Wen-xian. An algorithm for selecting ISAR imaging intervals based on the scatter-signal property [J]. Signal Processing, 2007, 23(5): 705-709.[12]Chen V C and Miceli W J. Simulation of ISAR imaging of moving targets [J].IEE Proc Radar Sonar Navigation.2001, 148(3):160-166
