应用于低对比度扩展目标观测的大型阵列太阳自适应光学电子系统的设计与实现

费玮玮; 王长清; 刘濮鲲; 蔡惠智; 姜爱民; 唐清善

doi:10.3724/SP.J.1146.2010.00025

应用于低对比度扩展目标观测的大型阵列太阳自适应光学电子系统的设计与实现

doi: 10.3724/SP.J.1146.2010.00025

基金项目:

国家自然科学基金(10778628)资助课题

计量
- 文章访问数: 3144
- HTML全文浏览量: 85
- PDF下载量: 795
- 被引次数: 0
出版历程
- 收稿日期: 2010-01-11
- 修回日期: 2010-05-11
- 刊出日期: 2010-12-19

The Design of Large Array Solar Adaptive Optics Electronic System for Observation of Low Contrast Extended Object

摘要

摘要: 自适应光学由于能够显著提高空间分辨率，在天文观测领域日益得到广泛的应用。与通常应用于恒星观测的夜天文自适应光学技术相比，对太阳表面低对比度扩展目标的观测校正一直是自适应光学中的难点。该文针对太阳观测中的低对比度扩展目标特性，采用FFT协方差相关算法，初步实现了大型阵列自适应光学电子系统。该系统采用阵列DSP和FPGA协同工作的架构，由低阶相关跟踪系统和高阶波前处理系统两部分组成。初步实验结果表明，系统能够满足预先设计的要求，并且具有较好的灵活性、通用性和扩展性。
- 太阳自适应光学 /
- 扩展目标 /
- 协方差相关算法 /
- 波前处理 /
- 相关跟踪
Abstract: Adaptive optics has wide applications in astronomical observation realm because of its high capacity in improving the spatial resolution. Compared with night astronomical adaptive technology for star observation, the observation and correction for low contrast extended target at the solar surface is always a difficulty in adaptive optics. In reference to low contrast extended character of adoptive optics in solar observation, FFT correlation coefficients algorithm is utilized and a large array adaptive optoelectronic system is designed. The system, with DSP+FPGA architecture, consists of low-order correlation tracking part and high-order wave-front processing part. The experimental result shows that the system well satisfies pre-design requirements and thus demonstrates good flexibility, versatility and scalability of the scheme.
- Solar adaptive optics /
- Extended object /
- Correlation coefficients algorithm /
- Wave-front process /
- Correlation tracking

HTML全文

参考文献(1)

饶长辉, 姜文汉, 张雨东等. 云南天文台1.2 m望远镜61单元自适应光学系统[J]. 量子电子学报, 2006, 23(3): 295-302.Rao Chang-hui, Jiang Wen-han, and Zhang Yu-dong, et al.. 61-element adaptive optical system for 1.2 m telescope of Yunnan Observatory. Chinese Journal of Quantum Electronics, 2006, 23(3): 295-302.[2]郑文佳, 王春鸿, 姜文汉等. 基于脉动阵列的自适应光学实时波前处理机设计[J].光电工程.2008, 34(5):44-49Zheng Wen-jia, Wang Chun-hong, and Jiang Wen-han, et al.. Design and analysis of real-time adaptive optics wavefront processor based on systolic array. Opto-Electronic Engineering, 2008, 34(5): 44-49.[3]闫光辉, 王春鸿, 黄奎. 基于双ADSP-TS201的波前信号处理试验平台设计[J]. 仪器仪表用户, 2008, 15(5): 89-91.Yan Guang-hui, Wang Chun-hong, and Huang Kui. The design of wavefront processing test platform based on double ADSP-TS201. Electronic Instrumentation Customer, 2008, 15(5): 89-91.[4]高越, 赵丹培, 姜志国. 基于小波变换的空间目标图像去噪方法[J]. 电子器件, 2009, 32(3): 716-720.Gao Yue, Zhao Dan-pei, and Jiang Zhi-guo. A denoising method based on wavelet for image of space. Chinese Journal of Electron Devices, 2009, 32(3): 716-720.[5]Rao Chang-hui, Jiang Wen-han, and Ling Nin. Tracking algorithm for low contrast extened object[J]. Acta Astronmica Sinica, 2001, 42(3): 329-338.[6]彭晓峰, 李梅, 饶长辉. 基于绝对差分算法的相关HS波前处理机设计[J]. 光电工程, 2008, 35(12): 18-22.Peng Xiao-feng, Li Mei, and Rao Chang-hui. Design of correlating Hartmann-Shack wavefront processor based on absolute difference algorithm. Opto-Electronic Engineering, 2008, 35(12): 18-22.[7]Rimmele T, Richards K, and Hegwer S, et al.. First results from the NSO/NJIT solar adaptive optics system[J].SPIE.2004, 5171:179-186[8]Smithson R and Tarbell T D. Correlation tracking study for meter-class solar telescope on space shuttle. Lockheed Palo Alto Res.Lab.1977.[9]姜爱民. 相关跟踪器研制[D]. [博士论文], 中国科学院国家天文台, 2004.[10]Jiang Ai-min. Studies on correlation tracker[D]. [Ph.D. dissertation], National Astronomical Observatories, Chinese Academy of Sciences, 2004.[11]Jiang W H and Li H G. Hartmann-Shack wavefront sensing and wavefront control algorithm[J].SPIE.1990, 1271:82-93[12]刘书明, 罗勇江. ADSP-TS20XS系列DSP原理与应用设计[M]. 北京: 电子工业出版社, 2007: 6-9.
