一种机载双天线InSAR基线动态测量方法

王海亮; 刘忠胜; 向茂生; 韦立登

doi:10.3724/SP.J.1146.2010.00006

一种机载双天线InSAR基线动态测量方法

doi: 10.3724/SP.J.1146.2010.00006

王海亮^{①② 刘忠胜,},
刘忠胜,
向茂生,
韦立登

基金项目:

国家863计划项目(2007AA120302)和973计划项目(2009CB724003)资助课题

计量
- 文章访问数: 3331
- HTML全文浏览量: 93
- PDF下载量: 809
- 被引次数: 0
出版历程
- 收稿日期: 2010-01-08
- 修回日期: 2010-06-02
- 刊出日期: 2010-12-19

The Dynamic Measurement for the Baseline of Airborne Dual-antenna InSAR

摘要

摘要: 机载双天线InSAR系统两个天线非刚性连接时，为保证高程测量精度和成像质量，必须对干涉基线进行动态精密的测量。该文研究了一种基于单相机和激光测距仪组合的动态基线测量方法，通过分别测量两个天线的中心位置和姿态，得到干涉基线长度和基线角。论文对该方法进行了原理性研究和地面验证实验，实验通过可精确控制轨迹的运动平台模拟天线运动，实验结果表明该方法在8 m摄影距离处位置测量精度优于0.2 mm，姿态角精度优于70，是动态测量干涉基线的有效方法。
- 干涉合成孔径雷达 /
- 基线测量 /
- 近景摄影测量 /
- 单像空间后方交会
Abstract: In this paper, a method for dynamic measurement of non-rigid baseline of dual-antenna InSAR is presented and discussed. In this scheme, the position and orientation of the antenna is obtained by using a CCD camera and a laser range finder together. In this paper, the research of principle and experiments are carried out. In the experiments, the movement of the antenna is created by some equipments, the tracks of which can be controlled accurately. The results of experiments show that the errors of position and attitude are less than 0.2mm and 70 arcseconds. The method is applicable to determine the baseline of dual-antenna dynamically.
- InSAR /
- Baseline measurement /
- Close range photogrammetry /
- Single image space resection

HTML全文

参考文献(1)

吴一戎, 李广云, 王保丰等. 单台相机机载InSAR基线动态测量方法研究[J].电子与信息学报.2005, 27(6):999-1001浏览Wu Yi-rong, Li Guang-yun, Wang Bao-feng, et al.. The dynamic measurement scheme based on single camera for the airborne InSAR baseline[J].Journal of Electronics Information Technology.2005, 27(6):999-1001[2]袁孝康. 星载合成孔径雷达导论[M]. 北京：国防工业出版社，2003: 221-229.[3]Yuan Xiao-kang. Introduce to the spaceborne synthetic aperture radar[M]. Beijing: National Defense Industry Press, 2003: 221-229.[4]冯文灏. 近景摄影测量[M]. 武汉: 武汉大学出版社, 2002: 9-10.Feng Wen-hao. Close Range Photogrammetry[M]. Wuhan：Wuhan University Press, 2002: 9-10.[5]Ghosh S K. Analytical Photogrammetry[M]. New York and Oxford: Pergamon Press, 1979: 62-69.[6]Wang Hai-liang, Xiang Mao-sheng, and You Hong-jian, et al.. Precision pose estimation at close range using single camera and laser range finder[C]. 2008 International Conference on Optical Instruments and Technology, Beijing, November 2008, Proceedings of SPIE, 2008,Vol.7160: 71601A1-71601A8.[7]Ababsa F and Mallem M. Robust camera pose estimation combining 2D/3D points and lines tracking[C]. ISIE 2008. IEEE International Symposium on Industrial Electronics, 2008. Cambridge, UK, June 30-July 2, 2008: 774-779.[8]Burschka D and Mair E. Direct pose estimation with a monocular camera[C]. RobVis 2008, LNCS 4931, 2008: 440-453.[9]于起峰, 尚洋. 摄像测量学原理与应用研究[M]. 北京: 科学出版社, 2009: 81-91.[10]Yu Qi-feng and Shang Yang. Videometrics: Principles and Researches[M]. Beijing: Science Press, 2009: 81-91.
