NURBS曲面建模的电大目标的宽带RCS快速计算

关莹; 龚书喜; 张帅; 路宝; 洪涛

doi:10.3724/SP.J.1146.2009.01637

NURBS曲面建模的电大目标的宽带RCS快速计算

doi: 10.3724/SP.J.1146.2009.01637

基金项目:

国家自然科学基金(60801042)资助课题

计量
- 文章访问数: 3562
- HTML全文浏览量: 109
- PDF下载量: 818
- 被引次数: 0
出版历程
- 收稿日期: 2009-12-25
- 修回日期: 2010-05-07
- 刊出日期: 2010-11-19

Fast Computation of Wideband RCS of Electrically Large Targets Modeled with NURBS Surfaces

摘要

摘要: 该文采用物理光学方法(PO)，快速计算了非均匀有理B样条 (NURBS) 曲面建模的电大目标的时域瞬态散射和宽带雷达截面(RCS)。通过对频域物理光学散射场表达式进行逆傅里叶变换推导出卷积形式的瞬态散射表达式；对频域物理光学积分进行逆傅里叶变换得到时域物理光学积分的表达式。为了避免数值积分的使用，将NURBS曲面等参数离散为一组三角面片，运用Radon变换得到了时域和频域物理光学积分的精确闭式表达式。遮挡消隐时使用改进的z-buffer方法进行了加速。对时域瞬态散射场快速傅里叶变换得到目标的宽带RCS。文中计算了高斯脉冲平面波入射下模型的瞬态散射响应和宽带RCS，数值结果表明该文方法具有很高的计算精度，且计算速度快于传统时域物理光学法(TDPO)。
- 宽频带RCS /
- NURBS曲面 /
- 时域物理光学积分 /
- Radon变换 /
- z-buffer算法
Abstract: The Physical Optics (PO) algorithm is utilized to compute the transient scattering response and wideband Radar Cross Section (RCS) of electrically large targets modeled with NonUniform Rational B-Spline (NURBS) surfaces. The formula for the time-domain scattered field is obtained with an inverse Fourier transform, which contains a convolution product. The time-domain PO integral is also derived with the inverse Fourier transform. In order to avoid the utilization of numerical integrations, the NURBS surfaces are discretized into small triangular facets, and Radon transform is introduced to obtain closed-form expressions for the time-domain and frequency-domain PO integrals. The improved z-buffer technique is used in the judgement and elimination of shadows for the sake of acceleration. The wideband RCS is obtained with the Fast Fourier Transform (FFT). The RCS of several targets is calculated under Gaussian-pulse plane wave incidence. Results show that the proposed method has a high accuracy and is faster than the traditional Time-Domain Physical Optics (TDPO).
- Wideband RCS /
- NURBS surfaces /
- Time-Domain PO (TDPO) integral /
- Radon transform /
- z-buffer algorithm

HTML全文

参考文献(1)

Domingo M, Rivas F, and Prez J, et al.. Computation of the RCS of complex bodies modeled using NURBS surfaces[J].IEEE Antennas and Propagation Magazine.1995, 37(6):36-47[2]Guan Y, Gong S, and Xu Y, et al.. Computation of RCS of targets modeled with trimmed NURBS surfaces[J].Electronics Letters.2009, 45(21):1092-1093[3]Bourlier C and Pouliguen P. Useful analytical formulae for near-field monostatic radar cross section under the physical optics: far-field criterion[J].IEEE Transactions on Antennas and Propagation.2009, 57(1):205-214[4]Sun En-yuan and Rusch W V T. Time-domain physical-optics[J].IEEE Transactions on Antennas and Propagation.1994, 42(1):9-15[5]Meng R, Dongming Z, and Ying L, et al.. Coupled TDIE-PO method for transient scattering from electrically large conducting objects[J].Electronics Letters.2008, 44(4):258-259[6]Faghihi F and Heydari H. A combination of time domain finite element-boundary integral with time domain physical optics for calculation of electromagnetic scattering of 3-D structures[J].Progress in Electromagnetics Research.2008, Vol. 79:463-474[7]杨凌霞, 葛德彪, 魏兵. 电大目标电磁散射的TD-PO分析[J].电波科学学报.2007, 22(4):552-556Yang Ling-xia, Ge De-biao, and Wei Bing. Analysis of large-scale EM scattering problems by using TD-PO method[J]. Chinese Journal of Radio Science, 2007, 22(4): 552-556.[8]Prez J and Ctedra M F. Application of physical optics to the RCS computation of bodies modeled with NURBS surfaces[J].IEEE Transactions on Antennas and Propagation.1994, 42(10):1404-1411[9]Blkbas D and Arif Ergin A. A radon transform interpretation of the physical optics integral[J].Mircrowave and Optical Technology Letters.2005, 44(3):284-288[10]Serim H A and Arif Ergin A. Computation of the physical optics integral on NURBS surfaces using a radon transform interpretation[J]. IEEE as and Wireless Propagation Letters, 2008, Vol. 7, Issue 99: 70-73.[11]Cox M G. The numerical evaluation of B-splines[J].IMA Journal of Applied Mathematics.1972, 10(2):134-149[12]Lischinski D and Gonczarowski J. Improved techniques for ray tracing parametric surfaces[J].Visual Computer.1990, 6(3):134-152[13]Zha F T, Gong S X, and Xu Y X, et al.. Fast shadowing technique for electrically large targets using z-buffer[J].Journal of Electromagnetic Waves and Applications.2009, 23(2/3):341-349[14]葛德彪, 闫玉波. 电磁波时域有限差分方法[M]. 西安: 西安电子科技大学出版社, 2005, 第2版: 118-121.[15]阮颖铮等. 雷达截面与隐身技术[M]. 北京: 国防工业出版社, 1998: 102.
