基于分子印迹聚合膜的胆固醇丝网印刷生物传感芯片

薛茜男; 边超; 任振兴; 孙楫舟; 卞贺明; 韩泾鸿; 夏善红

doi:10.3724/SP.J.1146.2009.01611

基于分子印迹聚合膜的胆固醇丝网印刷生物传感芯片

doi: 10.3724/SP.J.1146.2009.01611

基金项目:

国家自然科学基金项目(60672019)资助课题

计量
- 文章访问数: 3907
- HTML全文浏览量: 125
- PDF下载量: 898
- 被引次数: 0
出版历程
- 收稿日期: 2009-12-18
- 修回日期: 2010-05-04
- 刊出日期: 2010-11-19

Screen Printing Bio-chip Sensor for Cholesterol Detection Based on Molecular Imprinting Self-assembled Film

摘要

摘要: 该文基于自组装技术在丝网印刷金电极表面制备分子印迹膜，研制胆固醇电化学仿生生物传感芯片。利用扫描电镜(SEM)对平面裸金电极、厚膜裸金电极及其修饰电极进行了形貌的分析比较，采用循环伏安分析法对电极修饰过程的电化学特性进行表征，采用计时电流法对胆固醇生物传感芯片的浓度响应特性进行检测。结果表明, 基于丝网印刷工艺的厚膜电极不仅能满足自组装分子印迹仿生膜的修饰，而且电极表面具有明显的纳米放大效应。传感器对0~700 nM不同浓度胆固醇进行检测，线性范围50 nM~700 nM，灵敏度达到-4.94 A/[lg(nM)]，线性相关系数为0.994。该胆固醇传感芯片具有较高的准确性，检测准确度达到了99.56%。
- 电化学传感芯片 /
- 分子印迹 /
- 自组装单层膜 /
- 胆固醇 /
- 丝网印刷
Abstract: An electrochemical bionic sensor for cholesterol detection is developed with molecular imprinting self-assembled film deposited on the screen printed gold electrode. The surface topography of planar bare gold electrode and thick film bare gold electrode are compared with Scanning Electron Microscope (SEM). The electrochemical characteristics of the electrode during modification are studied with cyclic voltammetry technique. The results show that thick film electrode by screen printing technology is suited to the modification of molecular imprinting self-assembled film, and exhibits obvious amplification at nano level. The response of the sensor to the concentration of cholesterol is detected with chronoamperometric measurements. Cholesterol between 0 and 700 nM are detected with this sensor. The linearity range is from 50 nM to 700 nM with the sensitivity of -4.94 A/[lg(nM)] and linearly dependent coefficient of 0.994. And this cholesterol sensor has high accuracy, which reaches 99.56%.
- Electrochemical sensor /
- Molecular imprinting /
- SAM /
- Cholesterol /
- Screen printing

HTML全文

参考文献(1)

Hsieh R Y, Tsai H A, and Syu M J. Designing a molecularly imprinted polymer as an artificial receptor for the specific recognition of creatinine in serums[J].Biomaterials.2006, 27(9):2083-2089[2]Shinkai S and Takeuchi M. Molecular design of synthetic receptors with dynamic, imprinting, and allosteric functions[J].Biosensor Bioelectronics.2004, 20(6):1250-1259[3]Hou Chang-jun, Liu Xiao-juan, and Huo Dan-qun, et al.. Application of molecular imprinting technique in field of organophosphorus pesticide detection. Transducer and Microsystem Technologies, 2009, 28(4): 5-8.[4]Tabushi I, Kurihara K, and Naka K, et al.. Supramolecular sensor based on SnO2 electrode modified with octadecylsilyl mono1ayer having molecular binding sites[J].Tetrahedron Letter.1987, 28(37):4299-4302[5]Dickert F L, Lieberzeit P, and Tortschanoff M. Molecular imprints as artificial antibodies-a new generation of chemical sensors[J].Sensors and Actuators B: Chemical.2000, 65(1-3):186-189[6]Turnera N W, Wrighta B E, Hladya V, and Brittb D W. Formation of protein molecular imprints within Langmuir monolayers: a quartz crystal microbalance study. Journal of Colloid and Interface Science, 2007, 38(1): 71-80.[7]Vallano P T and Remcho V T. Highly selective separations by capillary electrochromatography: molecular imprint polymer sorbents[J].Journal of Chromatography A.2000, 87(1-2):125-135[8]Matsushita T, Nishikawa T, Yamashita H, Kishimoto J, and Okuno Y. Development of new single-mode waveguide surface plasmon resonance sensor using a polymer imprint process for high-throughput fabrication and improved design flexibility[J].Sensors and Actuators B: Chemical.2008, 129(2):881-887[9]Baldini F, Carloni A, Giannetti A, Porro G, and Trono C. An optical PMMA biochip based on fluorescence anisotropy: Application to C-reactive protein assay[J].Sensors and Actuators B: Chemical.2009, 139(1):64-68[10]Surez-Rodrguez J L and Daz-Garca M E. Flavonol fluorescent flow-through sensing based on a molecular imprinted polymer[J].Analytica Chimica Acta.2000, 405(1-2):67-76[11]Harborn U, Xie B, Venkatesh R, and Danielsson B. Evaluation of a miniaturized thermal biosensor for the determination of glucose in whole blood[J].Clinica Chimica Acta.1997, 267(2):225-237[12]Alava T, Berthet-Duroure N, and Ayela C, et al.. Parallel acoustic detection of biological warfare agents surrogates by means of piezoelectric immunochips[J].Sensors and Actuators B: Chemical.2009, 138(2):532-538[13]Rodrigues P N, Sakai Y, and Fujii T. Cell-based microfluidic biochip for the electrochemical real-time monitoring of glucose and oxygen[J].Sensors and Actuators B: Chemical.2008, 132(2):608-613[14]Hedborg E, Winquist F, Lundstrm I, Andersson L I, and Mosbach K. Some studies of molecularly-imprintedpolymer membranes in combination with field-effect devices[J].Sensors and actuators A: Physical.1993, 37-38(6-8):796-799[15]Dickert F L and Hayden O. Molecular imprinting in chemical sensing[J].TrAC Trends in Analytical Chemistry.1999, 18(3):192-199[16]Gilmartin M A T, Hart J P, and Patton D T. Prototype, solid-phase, glucose biosensor[J].Analyst.1995, 120(7):1973-1981[17]Palchetti I, Cagnini A, Carlo M D, Coppi C, Mascini M, and Turner A P F. Determination of anticholinesterase pesticides in real samples using a disposable biosensor[J].Analytica Chimica Acta.1997, 337(3):315-321
