基于窄带测距信息的空间目标微动特征检测与估计

马梁; 王雪松; 李永祯; 刘进

doi:10.3724/SP.J.1146.2009.01572

基于窄带测距信息的空间目标微动特征检测与估计

doi: 10.3724/SP.J.1146.2009.01572

基金项目:

国家自然科学基金重点项目(60736006)和国家自然科学基金面上项目(60875019) 资助课题

计量
- 文章访问数: 2991
- HTML全文浏览量: 84
- PDF下载量: 712
- 被引次数: 0
出版历程
- 收稿日期: 2009-12-08
- 修回日期: 2010-03-16
- 刊出日期: 2010-10-19

Detection and Estimation for the Character of Micro-Motion Based on the Narrowband Tracing Information

摘要

摘要: 微动目标被线性调频信号照射时，由于距离-多普勒耦合效应，微多普勒的存在会使得目标测量距离发生偏差。该文以匀速转动目标为例，从理论上证明了这种测距偏差随时间呈正弦规律变化，并且可以被跟踪雷达所观测。在此基础上，针对窄带跟踪雷达系统，提出了一种目标微动特征检测与参数估计的新方法，以空间目标精密跟踪雷达的典型参数为依据，设计了仿真实验和暗室动态测量实验，分析结果证明了该文的观点以及检测与估计方法的有效性。
- 窄带跟踪雷达 /
- 微动目标检测 /
- 距离-多普勒耦合 /
- 线性调频信号
Abstract: Due to the range-Doppler coupling effect of the LFM signal, the micro-Doppler caused by the micro- motion targets will also bring the bias detection range. Take the even rotational speed target as an example, the change of this bias detection range with time obeys the sinusoid, and this bias is large enough for the narrowband tracking radar. A new detection and estimation algorithm for the character of micro-motion based on the narrowband tracking information is proposed in this paper. The simulation result and the dynamic measure date of precession target in microwave anechoic chamber, which are designed according to the typical parameters of the tracking radar for the special targets, validate the conclusion of this paper and the effectiveness of detection and estimation algorithm.
- Narrowband tracking radar /
- Micro-motion target detection /
- Range-Doppler coupling /
- LFM signal

HTML全文

参考文献(1)

[1] 庄钊文, 刘永祥, 黎湘. 目标微动特性研究进展[J].电子学报.2007, 35(3):520-525 Zhuang Zhao-wen, Liu Yong-xiang, and Li Xiang. The achievements of target characteristic with micro-motion[J]. Acta Electronica Sinica, 2007, 35(3): 520-525. [2] 王涛. 弹道中段目标极化域特征提取与识别[D]. [博士论文], 国防科技大学, 2006. [3] Wang Tao. Feature extraction and recognition of targets in ballistic midcourse in polarization-domain [D]. [Ph.D. dissertation], National University of Defense Technology, 2006. [4] Chen V C, Li F, and Ho S S, et al.. Micro-Doppler effect in radar: phenomenon, model and simulation study[J].IEEE Transactions on Aerospace and Electronic Systems.2006, 42(1):2-21 [5] Chen V C, Li F, Ho S S, and Wechsler H. Analysis of micro-Doppler signatures[J].IEE Proceedings Radar Sonar Navigation.2003, 150(4):271-276 [6] 刘进, 马梁, 王雪松, 王国玉. 微多普勒的参数化估计方法[J]. 信号处理, 2009, 25(11): 1759-1765. Liu Jin, Ma Liang, Wang Xue-song, and Wang Guo-yu. Extraction method of micro-Doppler based on TFD-Hough transform[J]. Signal Processing, 2009, 25(11): 1759-1765. [7] Sun Hui-xia and Liu Zheng. Micro-Doppler feature extraction for ballistic missile warhead[C]. International Conference on Information and Automation Proceedings, Zhangjiajie, China, June 20-23, 2008: 1333-1336. [8] 胡杰民, 付耀文, 黎湘. 空间锥体目标进动周期估计[J].电子与信息学报.2008, 30(12):2849-2853浏览 Hu Jie-min, Fu Yao-wen, and Li Xiang. Precession cycle estimation of cone-shaped spatial target[J].Journal of Electronics Information Technology.2008, 30(12):2849-2853 [9] 贺思三, 周剑雄, 付强. 利用一维距离像序列估计弹道中段目标进动参数[J]. 信号处理, 2009, 25(6): 925-929. He Si-san, Zhou Jian-xiong, and Fu Qiang. Using HRRR sequence to estimate the precession parameters of midcourse target[J]. Signal Processing, 2009, 25(6): 925-929. [10] 赵峰. 弹道导弹防御跟踪制导雷达跟踪技术研究[D]. [博士论文], 国防科技大学, 2007. [11] Zhao Feng. Study on detection techniques of tracking and guiding radars in ballistic missile defense [D]. [Ph.D. dissertation], National University of Defense Technology, 2007. [12] 林茂庸, 柯有安. 雷达信号理论[M]. 北京: 国防工业出版社, 1984: 64-72. [13] Lin Mao-yong and Ke You-an. The Theory of Radar Signals[M]. Beijing: National Defense Industry Press, 1984: 64-72. [14] Steven M key. Fundamentals of Statistical Signal Processing, Volume II: Detection Theory [M]. New Jersey: Prentice Hall Press, 1998: 261-271, 279-296.
