基于极化二元阵雷达的空域虚拟极化滤波算法

刘勇; 李永祯; 戴幻尧; 王雪松

doi:10.3724/SP.J.1146.2009.01512

基于极化二元阵雷达的空域虚拟极化滤波算法

doi: 10.3724/SP.J.1146.2009.01512

基金项目:

国家自然科学基金(60736006)和国家自然科学基金青年科学基金(60802078)资助课题

计量
- 文章访问数: 3402
- HTML全文浏览量: 98
- PDF下载量: 1150
- 被引次数: 0
出版历程
- 收稿日期: 2009-11-27
- 修回日期: 2010-06-11
- 刊出日期: 2010-11-19

The Spatial Virtual Polarization Filtering Algorithm Based on Dual Polarized Antenna Radar

摘要

摘要: 极化滤波利用干扰信号和目标信号的极化状态差异，可有效抑制有源压制干扰，然而，现有极化雷达需要两路发射通道和接收通道，存在系统复杂、实现代价高等诸多困难。该文提出了一种新体制极化雷达模型极化二元阵雷达，该系统仅需一路发射通道和接收通道即可实现极化测量。基于极化二元阵天线的空域极化特性，建立了有源压制干扰、目标回波的接收信号模型，研究了抑制有源压制干扰的空域虚拟极化滤波算法，仿真实验结果表明：对于窄带噪声调频干扰，信干比(SIR)改善因子能达到20 dB以上。
- 极化二元阵雷达 /
- 空域极化特性 /
- 极化滤波 /
- 有源压制干扰 /
- 改善因子
Abstract: Based on polarization differences between jamming signal and target echo, polarization filter can combat active suppression jamming effectively. However, traditional polarization radars consist of two transmitting channels and receiving channels, facing such limits as system complexity, high realization cost. As a result, a novel polarized radar model named as dual polarized antenna radar is advanced. It can realize polarization measurement using only single transmitting channel and receiving channel. Based on spatial polarization characteristic of dual polarized antenna, received signal models of active suppression jamming and target echo are given, and spatial virtual polarization filtering algorithm to counter active suppression jamming is advanced. Following results can be obtained from simulations: For narrowband noise frequency modulation jamming, Signal Interference Ratio (SIR) improvement factor can be greater than 20 dB.
- Dual polarized antenna radar /
- Spatial polarization characteristic /
- Polarization filtering /
- Active suppression jamming /
- Improvement factor

HTML全文

参考文献(1)

王国玉, 汪连栋等. 雷达电子战系统数学仿真与评估[M]. 北京: 国防工业出版社, 2004: 278-284.[2]刘德树. 雷达反对抗的基本理论与技术[M]. 北京: 北京理工大学出版社, 1988: 103-120.[3]Wang Xue-song, Chang Yu-liang, and Dai Da-hai, et al.. Band characteristics of SINR polarization filter [J].IEEE Transactions on Antennas and Propagation.2007, 55(4):1148-1154[4]毛兴鹏, 刘永坦, 邓维波. 频域零相移多凹口极化滤波器[J].电子学报.2008, 36(3):537-542Mao Xing-peng, Liu Yong-tan, and Deng Wei-bo. Frequency domain null phase-shift multinotch polarization filter [J]. Acta Electronica Sinica, 2008, 36(3): 537-542.[5]张扬, 徐建平. 变步长极化对消迭代滤波算法[J]. 电子科技大学学报, 2009, 38(1): 1-4.Zhang Yang and Xu Jian-ping. Variable step size APC iterative-filtering algorithm[J]. Journal of University of Electronic Science and Technology of China, 2009, 38(1): 1-4.[6]吴文洲, 潘健等. 基于遗传算法极化雷达反干扰接收极化选择[J].现代雷达.2008, 30(4):67-71[7]Wu Wen-zhou and Pan Jian, et al.. Receiving antenna polarization choice of polarization radar system based on[8]genetic algorithm [J]. Modern Radar, 2008, 30(4): 67-71[9]庞礴, 潘健等. 干扰极化状态的自适应估计方法研究[J]. 现代雷达, 2009, 31(6): 38-46.Pang Bo and Pan Jian, et al.. A study on adaptive polarization estimation method [J]. Modern Radar, 2009, 31(6): 38-46.[10]Poelman A J. Virtual polarisation adaptation: a method for increasing the detection capability of a radar system through polarisation-vector processing [J].IEE Proceeding, Part F- Communications, Radar and Signal Processing.1981, 128(5):261-270[11]李金梁, 罗佳, 常宇亮等. 基于天线空域极化特性的虚拟极化接收技术[J]. 电波科学学报, 2009, 24(3): 389-393.Li Jin-liang, Luo Jia, and Chang Yu-liang, et al.. Virtual polarization receiver based on the spatial polarization characteristics of antenna [J]. Chinese Journal of Radio Science, 2009, 24(3): 389-393.[12]束咸荣, 何炳发. 论天线收发方向图的非互易性[J]. 电波科学学报, 2009, 24(2): 293-296.Shu Xian-rong and He Bing-fa. On non-reciprocity between received and transmitting patterns of antenna [J]. Chinese Journal of Radio Science, 2009, 24(2): 293-296.[13]Mott.H著, 林昌禄等(译). 天线和雷达中的极化[M]. 成都: 电子科技大学出版社, 1989: 131-142.
