非规则曲面共形阵列的优化设计

张玉洁; 龚书喜; 王文涛; 凌劲

doi:10.3724/SP.J.1146.2009.01212

非规则曲面共形阵列的优化设计

doi: 10.3724/SP.J.1146.2009.01212

计量
- 文章访问数: 3388
- HTML全文浏览量: 78
- PDF下载量: 859
- 被引次数: 0
出版历程
- 收稿日期: 2009-09-11
- 修回日期: 2010-04-19
- 刊出日期: 2010-09-19

Optimization Design of Conformal Array on an Irregular Curved Surface

摘要

摘要: 该文对一个共形在非规则曲面上的H形微带阵列进行了优化及设计。采用自适应混合遗传算法对此共形阵列的辐射方向图进行了优化设计。优化后的辐射方向图在水平方向几乎达到了全向辐射，俯仰面方向图集中辐射在水平方向。最后考虑到相位误差，对优化结果进行了误差分析。结果表明，该文所提出的优化算法对于非规则曲面上共形阵列的设计是有效和可行的。
- 天线 /
- 共形微带阵 /
- 非规则曲面 /
- 自适应混合遗传算法
Abstract: An H-shaped conformal microstrip antenna array mounted on an irregular curved surface is optimized and designed in this paper and the radiation pattern of this conformal array is synthesized using the Self-adaptive Hybrid Genetic Algorithms (SHGA). The optimized azimuth radiation pattern of the conformal array is almost omnidirectional and the elevation radiation pattern is concentrated in the horizontal direction. Finally, the optimized results are analyzed in view of the phasic error. The results show that the proposed procedure is an effective and feasible method for designing the conformal antenna array on an irregular curved surface.
- Antenna /
- Conformal microstrip array /
- Irregular curved surface /
- Self-adaptive Hybrid Genetic Algorithms (SHGA)

HTML全文

参考文献(1)

Werner D H, Allard R J, Martin R A, and Mittra R. A reciprocity approach for calculating radiation patterns of arbitrarily shaped microstrip antennas mounted on circularly cylindrical platforms[J].IEEE Transactions on Antennas Propagat.2003, 51(4):730-738[2]Gao De-yuan, Qi Zi-sen, Wang Bu-hong, and Guo Ying. Performance analysis of high resolution DOA estimation for conical conformal array. WiCOM 4th International Conference. Dalian, Oct 12-14, 2008: 1-4.[3]Morton T E and Pasala K M. Pattern synthesis and performance of conical arrays. Proceedings of the Thirty-Sixth Southeastern Symposium. Atlanta, GA, United States, 2004: 145-149.[4]Wang Bu-hong, Meng Ling-qin, and Guo Ying. Pattern synthesis of double-curved conformal paraboloidal array. Antennas and Propagation Society International Symposium. San Diego, CA, United states, July 5-12, 2008.[5]Josefsson L and Persson P. Conformal Array Antenna Theory and Design. New Jersey:Institute of Electrical and Electronics Engineers, Inc., 2006, Chapter 1, 4-9.[6]Allard R J, Werner D H, and Werner P L. Radiation pattern synthesis for arrays of conformal antennas mounted on arbitrarily shaped three-dimensional platforms using genetic algorithms[J].IEEE Transactions on Antennas Propagat.2003, 51(5):1054-1062[7]杜卫民. 低副瓣平面阵列天线设计. [硕士论文], 西安电子科技大学, 2008.[8]Du Wei-min, Low-sidelobe planar array antenna design. [ MA. dissertation], Xidian University, 2008.[9]Vani R M, Farida S F, and Hunagund P V. A study on rectangular microstrip antenna with group of slots for compact operation[J].Microwave and Optical Technology Letters.2001, 40(5):396-398[10]Lu Z B, Zhang A, and Hou X Y. Pattern synthesis of cylindrical conformal array by the modefied particle swarm optimization algorithm.[J]. Progress In Electromagnetics Research.2008,PIER 79:415-
