基于多场耦合的电子装备机箱结构优化设计

李鹏; 段宝岩; 胡凯博; 罗先义

doi:10.3724/SP.J.1146.2009.01183

基于多场耦合的电子装备机箱结构优化设计

doi: 10.3724/SP.J.1146.2009.01183

计量
- 文章访问数: 3187
- HTML全文浏览量: 126
- PDF下载量: 726
- 被引次数: 0
出版历程
- 收稿日期: 2009-09-08
- 修回日期: 2010-05-20
- 刊出日期: 2010-11-19

The Optimization Design of Electronic Equipments' Case Based on Multi-field-coupled Model

摘要

摘要: 电子装备机箱结构设计受到结构强度、通风散热和电磁屏效三方面的约束。实际工作中的电子装备受到结构位移场、温度场和电磁场的共同作用，它们都是机箱结构参数的函数。由于机箱的电磁场、温度场和结构位移场之间存在一定耦合关系，该文建立了电子装备的多场耦合模型，并在此基础上提出多场耦合的优化模型，可用于实际机箱结构的优化设计。最后，将其应用于某电子设备机箱实物的结构优化设计，取得了满意的结果。
- 电磁屏效 /
- 电子装备 /
- 多场耦合 /
- 优化设计
Abstract: Design of Electronic cabinet is constrained by structure intensity, ventilation and Shielding Effectiveness (SE). Practically, there are three fields affecting electronic equipment, electromagnetic, temperature, and elastic deformation fields which are functions of enclosure structure parameters. Because of the relationship between three fields, in this paper, a multi-field-coupled model called STEM is established. Furthermore, an optimization model based on STEM is proposed in this manuscript. Structure optimization is also proposed on a practical enclosure with satisfying result.
- Electromagnetic shielding /
- Electronic equipment /
- Multi-field-coupled /
- Optimal design

HTML全文

参考文献(1)

Archambeault B. Modeling and simulation validation for EMC applications[C]. IEEE International Symposium on Electromagnetic Compatibility, Seattle, WA, USA, Aug. 1999: 492-496.[2]Bogorad A L , Deeter M P, and August K A, et al.. Shielding Effectiveness and closeout methods for composite spacecraft structural panels[J].IEEE Transactions on Electromagnetic Compatibility.2008, 50(3):547-555[3]石峥, 杜平安, 刘建涛. 缝隙结构电磁屏蔽特性数值仿真建模方法研究[J]. 系统仿真学报, 2009, 21(24): 7732-7737.Shi Z, Du P A, and Liu J T. Study on modeling method for electromagnetic shielding simulation of aperture[J]. Journal of System Simulation, 2009, 21(24): 7732-7737.[4]平丽浩, 钱吉裕, 徐德好. 电子设备热控新技术综述[J]. 机械电子工程, 2008, 24(1): 1-10.Ping L H, Qian J Y, and Xu D H. A review of the thermal control technologies for electronic systems[J]. Electro- Mechanical Engineering, 2008, 24(1): 1-10.[5]曹志坤, 谷波, 顾众. 基于改进的支持向量机制冷陈列柜优化模型[J]. 上海交通大学学报, 2009, 43(9): 1427-1431.Cao Z K, Gu B, and Gu Z. Optimization model of refrigerated display cabinet based on modified support vector machine[J]. Journal of Shanghai Jiaotong University, 2009, 43(9): 1427-1431.[6]曾锐, 平丽浩, 鞠文耀. 电子设备多场耦合求解方法研究[J].现代雷达, 2008, 30(11): 103-106.Zeng R, Ping L H, and Ju W Y. A study on uncoupling method for electronic equipment multifield coupling problem[J]. Modern Radar, 2008, 30(11): 103-106.[7]陶文铨. 数值传热学(第2版)[M]. 西安：西安交通大学出版社, 2001: 1-25.[8]Deb K. Optimization for Engineering Design: Algorithms and Examples[M]. New Delhi: Prentice-Hall of India, 1998: 105-136.
