具有高稳定性的模式选择电路回旋行波管放大器

杜朝海; 刘濮鲲; 薛谦忠; 张世昌

doi:10.3724/SP.J.1146.2009.00953

具有高稳定性的模式选择电路回旋行波管放大器

doi: 10.3724/SP.J.1146.2009.00953

杜朝海^{①② 刘濮鲲,},
刘濮鲲,
薛谦忠,
张世昌

基金项目:

国家自然科学基金(60871051，60871047，60971072)资助课题

计量
- 文章访问数: 3565
- HTML全文浏览量: 88
- PDF下载量: 631
- 被引次数: 0
出版历程
- 收稿日期: 2009-07-02
- 修回日期: 2010-04-06
- 刊出日期: 2010-08-19

A Mode-selective-circuit Gyrotron-traveling-wave Amplifier with High Stability

摘要

摘要: 该文基于线性理论和自洽非线性理论，对具有模式选择特性的损耗陶瓷和金属环交替加载的Ka波段TE01模回旋行波管放大器进行理论建模和稳定性分析。分析表明损耗陶瓷加载波导具有模式选择特性，其传输特性类似于光滑圆波导；稳定性分析揭示了互作用系统自激振荡的内反馈机制。将理论分析与美国海军实验室的实验工作进行了比较，证明了该文理论模型的可靠性。该文的理论模型对回旋行波管放大器的设计具有一定的指导意义。
- 回旋行波管 /
- 损耗陶瓷 /
- 模式选择 /
- 稳定性
Abstract: This paper devotes to modeling and the stability study of a Ka-band TE01 mode gyrotron Traveling-Wave Tube (gyro-TWT) based on a modal selective circuit alternately loaded with lossy ceramic shells and metal rings. The linear theory and the self-consistent nonlinear theory are applied to analyze the stability of the equivalent interaction circuit. The study reveals that the lossy dielectric-loaded waveguide is with modal selective ability, and its propagation characteristics are similar to that of the circular empty waveguide. The internal feedback physics of the self-excited oscillations are revealed in the stability analysis. The consistency between the theoretical analysis and the experimental tests of American Naval Research Laboratory indicates the reliability of this study. The theoretical model in this paper brings guidance for future designing a gyro-TWT.
- Gyro-TWT /
- Lossy ceramic /
- Modal selective /
- Stability

HTML全文

参考文献(1)

Chu K R. The electron cyclotron maser[J].Reviews ofModern Physics.2004, 76(2):489-540[2]Chu K R and Chen H Y, et al.. Theory and experiment ofultrahigh-gain gyrotron traveling wave amplifier[J].IEEETransactions on Plasma Science.1999, 27(2):391-404[3]Garven M and Calame J P, et al.. A gyrotron-traveling-wavetube amplifier experiment with a ceramic loaded interactionregion[J].IEEE Transactions on Plasma Science.2002, 30(3):885-893[4]Calame J P and Garven M, et al.. Gyrotron-travelingwave-tube circuit based on lossy ceramics[J].IEEETransactions on Electron Devices.2002, 49(8):1469-1477[5]Song H H and McDermott D B, et al.. Theroy and experimentof a 94GHz gyrotron traveling-wave amplifier[J].Physics ofPlasmas.2004, 11(5):2935-2941[6]Sirigiri J R, Shapiro M A, and Temkin R J. High-power140-GHz quasioptical gyrotron traveling-wave amplifier[J].Physical Review Letters, 2003, 90(25): 258-302.[7]纵啸宇，薛谦忠，杜朝海. 损耗介质加载Ka波段TE01模回旋行波管放大器稳定性的分析[J].电子与信息学报.2009, 31(6):1483-1486浏览[8]Du Chao-hai, Liu Pu-kun, and Xue Qian-zhong, et al.. Effectof a backward wave on the stability of an ultrahigh gaingyrotron traveling-wave amplifier[J]. Physics of Plasmas,2008, 15(123107): 1-8.[9]Pershing D E and Nguyen K T, et al.. A TE11 Ka-bandgyro-TWT amplifier with high-average power compatibledistributed loss[J].IEEE Transactions on Plasma Science.2004, 32(3):947-956[10]Nguyen K T and Calame J P, et al.. Design of a Ka-bandgyro-TWT for radar applications[J].IEEE Transactions onElectron Devices.2001, 48(1):108-115[11]Du Chao-hai, Xue Qian-zhong, and Liu Pu-kun. Loss-inducedmodal transition in a dielectric-coated metal cylindricalwaveguide for gyro-traveling-wave-tube applications[J].IEEEElectron Device Letters.2008, 29(11):1256-1258[12]Du Chao-hai, Xue Qian-zhong, and Liu Pu-kun, et al.. Modaltransition and reduction in a lossy dielectric-coatedwaveguide for gyrotron-traveling-wave tube amplifierapplications[J].IEEE Transactions on Electron Devices.2009,56(5):839-845[13]殷瑞剑, 刘濮鲲. 3mm回旋行波放大器单阳极磁控注入式电子枪的设计[J].电子与信息学报.2008, 30(6):1507-1510浏览[14]Tigelis I G, Vomvoridis J L, and Tzima S. High-frequencyelectromagnetic modes in a dielectric-ring loaded beamtunnel[J].IEEE Transactions on Plasma Science.1998, 26(3):922-930[15]Tsai W C and Chang T H, et al.. Absolute instability in ahigh-order-mode gyrotron traveling-wave amplifier[J].[J].Physical Review E.2004,70:056402-
