子孔径NCS算法中虚假目标产生的机理与消除方法研究

李建阳; 常文革; 李悦丽

doi:10.3724/SP.J.1146.2009.00565

子孔径NCS算法中虚假目标产生的机理与消除方法研究

doi: 10.3724/SP.J.1146.2009.00565

计量
- 文章访问数: 3892
- HTML全文浏览量: 108
- PDF下载量: 560
- 被引次数: 0
出版历程
- 收稿日期: 2009-04-19
- 修回日期: 2009-12-22
- 刊出日期: 2010-05-19

The Theory Analysis of False Target in Sub-aperture Algorithm

摘要

摘要: 子孔径结构的引入是实现Ultra Wide Band SAR(UWB SAR)实时信号处理的关键。将子孔径结构与Nonlinear Chirp Scaling(NCS)算法相结合的子孔径NCS算法可以较好的实现UWB SAR实时信号处理，但子孔径结构的引入使得成像结果中存在虚假目标的影响。针对子孔径NCS算法中存在虚假目标的现象，该文从理论上分析了虚假目标产生的机理，并提出了对距离弯曲校正前的子孔径回波两端补零的改进子孔径NCS算法消除虚假目标，最后通过仿真和实测的UWB SAR回波数据验证了该文理论分析以及所提方法的正确性。
- 实时信号处理; UWB SAR; 子孔径NCS算法; 虚假目标
Abstract: The sub-aperture algorithm has great important role in SAR real-time processing. The algorithm combined the sub-aperture and Nonlinear Chirp Scaling (NCS) algorithm has good performance in real-time processing of UWB SAR. However the ghost or false targets exist in the algorithm based on sub-aperture. In this paper, the reason for ghost or false target existing is theoretically analyzed, furthermore, the method of eliminating the ghost is proposed using zero-padding with sub-aperture data. Finally, the validity is verified with simulation and real UWB SAR data.

HTML全文

参考文献(1)

Moreira A. real-time Synthetic Aperture Radar (SAR) processing with a new subaperture approach[J].IEEE Transactions on Geoscience and Remote Sensing.1992, 30(4):714-722[2]Yeo T S, Tan N L, Zhang C B, and Lu Y H. A new subaperture approach to high squint SAR processing[J].IEEE Transactions on Geoscience and Remote Sensing.2001, 39(5):954-968[3]Mittermayer J and Moreira A. Spotlight SAR processing using the extended Chirp scaling algorithm. IGARSS 1997, Singapore, 1997: 2021-2023.[4]王建, 薛国义, 周智敏等. 超宽带SAR子孔径NCS实时成像算法. 信号处理, 2008, 24(3): 390-394.Wang Jian, Xue Guo-yi, Zhou Zhi-min, and Song Qian. A new subaperture nonlinear Chirp scaling algorithm for real-time UWB SAR imaging. Signal Processing, 2008, 24(3): 390-394.[5]Simon-Klar C, Friebe L, Kloos H, Lieske H, Hinrichs W, and Pirsch P. A multi DSP board for real time SAR processing using the HiPAR-DSP 16. IGARSS 2002, Canada, 2002: 2750-2752.[6]Liu Jing, Wu Jing-wei, Wang Zhi-rui, and Hu Qing-rong.Airborne C-SAR (Synthetic Aperture Radar) real-time imaging system. APSAR Huangshan, China, 2007: 675-679.[7]Simon-Klar C, Kirscht M, Langemeyer S, Nolte N, and Pirsch P. An on-board real-time SAR processor for small platforms[J].Proceedings of SPIE.2004, Vol.5574:420-427[8]Tang Yue-sheng and Zhang Chang-yao. Multi-DSPs SAR real-time signal processing system based on cPCI BUS. APSAR Huangshan, China, 2007: 661-663.[9]Davidson G W, Cumming I G, and Ito M R. A Chirp scaling approach for processing squint mode SAR data[J].IEEE Transactions on Aerospace and Electronic Systems.1996, 32(1):121-133[10]王亮, 黄晓涛, 周智敏. 非线性Chirp Scaling在机载SAR成像中的应用. 系统工程与电子技术, 2007, 29(5): 723-727.Wang Liang, Huang Xiao-tao, and Zhou Zhi-min. Application of nonlinear Chirp scaling in airborne SAR imaging. Systems Engineering and Electronics, 2007, 29(5): 723-727.
