星载SpaceWire路由器的研究与设计
doi: 10.3724/SP.J.1146.2009.00464
Research and Design of on-Board Dynamic SpaceWire Router
-
摘要: 为满足航天器有效载荷间高速数据多路传输的未来发展需求,该文研究提出了基于SpaceWire的星载数据路由的设计方案。在SpaceWire总线标准网络层分析的基础上,结合虫孔路由原理构建路由器内部结构,提出了采用无阻断交差开关的SpaceWire路由器设计方案。在Simulink环境下建立了路由器仿真模型,并通过BWR解决了虫孔路由阻塞机制带来的刹车问题,使路由器的满负荷通信下的平均丢包率减少了70%。Abstract: In order to satisfy the requirement of aerocrafts multi- transmission for further development, this paper leads to a resolution about on-board SpaceWire routing technology. Based on the network level analysis of SpaceWire standard, it built the architecture of router with wormhole routing theory and non-blocking switch mechanism. A simulation model of router had been set to verify the design, and braking-problem from wormhole routing-blocking had been solved with BWR (Buffered Wormhole Routing), it reduces 70% average packet-losing ratio on full load communication.
