UC-PBG结构创建准TEM波导的仿真分析

张弛; 罗积润

doi:10.3724/SP.J.1146.2009.00111

UC-PBG结构创建准TEM波导的仿真分析

doi: 10.3724/SP.J.1146.2009.00111

张弛,
罗积润^①

计量
- 文章访问数: 3569
- HTML全文浏览量: 81
- PDF下载量: 1061
- 被引次数: 0
出版历程
- 收稿日期: 2009-01-20
- 修回日期: 2009-07-03
- 刊出日期: 2010-02-19

Analysis and Simulation of the Quasi-TEM Waveguide by Using UC-PBG Structure

Zhang Chi,
Luo Ji-run^①

摘要

摘要: 光子带隙(Photonic BandGap, PBG)，是指人造的周期性电介质结构，它使得在一定频率范围内的电磁波是禁止传播的，而单平面紧凑型光子带隙结构(UC-PBG)是一种以微带基片为载体的周期性平面光子带隙结构。该文用UC-PBG结构置换标准矩形波导窄边，可在UC-PBG结构的谐振频率点附近将TE10模转变成准TEM模。通过对整个系统进行仿真计算，证实了此方法切实有效，在Ku波段转换带宽达到450 MHz。
- 光子带隙; UC-PBG结构; 理想磁导体; 准TEM波导
Abstract: Photonic BandGap (PBG) is man-made periodic dielectric structure, which may control the propagation of electromagnetic waves in certain frequency range. And the Uniplanar Compact Photonic BandGap (UC-PBG) is a periodic photonic bandgap on a conductor-backed dielectric substrate. This paper introduces a waveguide using the UC-PBG structure, which replace the two bilateral sides of a rectangular waveguide. The simulations with Ansoft HFSS indicate that the TE10 mode can be converted to quasi-TEM mode in the range of 15.15 GHz-15.60 GHz with the UC-PBG structure.

HTML全文

参考文献(1)

温熙森. 光子/声子晶体理论与技术[M]. 北京: 科学出版社, 2006: 1-2.付云起, 袁乃昌, 温熙森. 微波光子晶体天线技术[M]. 北京:国防工业出版社, 2006: 54-58.[2]郑秋容, 袁乃昌, 付云起. 紧凑型电磁带隙结构在短路微带天线中的应用[J]. 电子与信息学报, 2007, 29(7): 1500-1502.Zheng Qiu-rong, Yuan Nai-chang, and Fu Yun-qi. Application of compact electromagnetic band-gap structure to shorted micro-strip antenna[J].Journal of Electronics Information Technology.2007, 29(7):1500-1502[3]黄玉兰. 微波电路中的光子带隙结构[J]. 西安邮电学院学报, 2008, 13(1): 22-24.Huang Yu-lan. Photonic bandgap structures in microwave circuits[J].Journal of Xian University of Post and Telecommunications.2008, 13(1):22-24[4]Yang Fei-ran, Ma Kuang-ping, and Qian Yong-xi, et al.. A Uniplanar Photonic Band-Gap (UC-PBG) structure and its application for microwave circuits[J].IEEE Transactions on Microwave Theory and Techniques.1999, 47(8):1509-1514[5]周焱, 苏东林, 翟禹. UC-PBG结构在微带滤波器设计中的应用[J]. 微波学报, 2005, 21(3): 32-35.Zhou Yan, Su Dong-ling, and Zhai Yu. Application of UC-PBG structure in microstrip filter [J]. Journal of Microwaves, 2005, 21(3): 32-35.[6]王伟, 曹祥玉, 王帅, 等. 平面型紧凑微波光子晶体研究[J]. 激光与红外, 2008, 38(9): 910-912.Wang Wei, Cao Xiang-yu, and Wang Shuai, et al.. Research on compact uniplanar microwave photonic crystals [J]. Laser ＆ Infrared, 2008, 38(9): 910-912.[7]吴万春. 集成固态微波电路[M]. 北京: 国防工业出版社, 1981: 38-39.[8]高葆新, 洪兴楠, 陈兆武, 等. 微波电路计算机辅助设计(下册)[M]. 北京: 清华大学出版社, 1988: 47-48.[9]Fei-ran Yang, Kuang-ping Ma, and Itoh T. A novel TEM waveguide using uniplanar compact photonic-bandgap (UC-PBG) structure[J].IEEE Transactions on Microwave Theory and Techniques.1999, 47(11):2092-2098
