微型SAR的数字下变频设计

王虹现; 李刚; 邢孟道; 张守宏

doi:10.3724/SP.J.1146.2008.01770

微型SAR的数字下变频设计

doi: 10.3724/SP.J.1146.2008.01770

计量
- 文章访问数: 4267
- HTML全文浏览量: 73
- PDF下载量: 1103
- 被引次数: 0
出版历程
- 收稿日期: 2008-12-24
- 修回日期: 2009-11-10
- 刊出日期: 2010-02-19

Design of Digital Down Converter of Mini SAR

摘要

摘要: 在微型SAR实时成像样机的设计中，对雷达回波在中频进行采样，然后采用数字下变频技术实现正交解调，可以减少系统的复杂性，提高雷达的数字化程度和性能。该文针对微型SAR方案中数字下变频设计中的难点，即采样频率高达2 Gsps，带宽900 MHz，实时处理的难度很大，根据具体设计参数优化了数字下变频的实现结构，重点比较了并行FIR滤波器和快行FIR滤波器的差别，然后在FPGA中编程实现了数字下变频模块，给出资源占用情况、运行速度和量化噪声影响，最后给出在微型SAR技术项目中的实际应用结果，理想的成像结果表明了该设计的正确性。
- 合成孔径雷达(SAR); 数字下变频(DDC); 模数转换(AD); FPGA
Abstract: In the designation of the real-time imaging machine of Mini SAR, the radar return signal is sampled in the intermediate frequency, then Digital Down Converter(DDC) is used to realize quadrature demodulate, which can reduce system complexity and improve radars performance. The difficulty in the design of the DDC of Mini SAR is firstly given in this paper, i.e. the sampling frequency is as high as 2Gsps and the bandwidth is 900MHz, which leads large difficulty in real-time processing. The optimal architecture of DDC based on real design parameters is given in the next, with the emphasis on the difference of the parallel FIR filter and fast FIR filter. Then the implementation of the DDC module using parallel processing with optimized structure in FPGA is given, the resource usage, running speed and quantity noise influence are given. Finally, the result of Mini SAR is given, which confirms the validity of the design.

HTML全文

参考文献(1)

苏涛, 何学辉, 吕林夏. 实时信号处理系统设计. 西安: 西安电子科技大学出版社, 2006: 41-42.[2]Su Tao.[J].He Xue-hui, and Lv Lin-xia. Real-time Signal Processing System Design. Xian: Xidian University Press.2006,:-[3]李早社, 禹卫东. 星载SAR实时成像处理器预处理器的FPGA实现. 现代雷达, 2007, 29(2): 38-40.Li Zao-she and Yu Wei-dong. FPGA implementation of preprocessor for spaceborne SAR imaging processor. Modern Radar, 2007, 29(2): 38-40.[4]Fudge J, Legako M, and Sehreiner C. An approach to efficient wideband digital down conversion. Proc IC SPAT, Toronto, 1998: 713-717.[5]杨明磊, 陈伯孝, 张守宏. 宽带信号的中频正交采样. 现代雷达, 2007, 29(3): 47-51.Yang Ming-lei, Chen Bo-xiao, and Zhang Shou-hong. Quadrature sampling of wideband IF signal. Modern Radar, 2007, 29(3): 47-51.[6]张嵘, 肖先赐. 任意中频带通信号多相数字下变频方法[J].电子与信息学报.2003, 25(9):1285-1289浏览Zhang Rong and Xiao Xian-ci. Polyphase based digital down conversion of random IF signal. Journal of Electronics and Information Technology, 2003, 25(9): 1285-1289.[7]李冰, 葛临东, 郑瑾. 一种改进的宽带数字下变频高效结构[J].电子与信息学报.2007, 29(8):1891-1894浏览Li Bing, Ge Lin-dong, and Zheng Jin. An improved efficient architecture for wideband digital down conversion. Journal of Electronics and Information Technology, 2007, 29(8): 1891-1894.[8]Stephan B, Thomas D, and Peter R. A real-time time-domain EMI measurement system for full-compliance measurements according to CISPR 16-1-1[J].IEEE Transactions on Electromagnetic Compatibility.2008, 50(2):259-267[9]Uwe Meyer-Baese. Digital Signal Processing with Field Programmable Aate Arrays (third edition). Springer, 2007: 165-207.
