无人机载软件接收机同步方案研究
doi: 10.3724/SP.J.1146.2008.01564
Investigation of Synchronization for Software Receivers on Unmanned Aerial Vehicles(UAVs)
-
摘要: 为确保无人飞机进行稳定的数据传输,该文提出了一种基于部分匹配滤波器和两级FFT的快速同步捕获算法,该算法能在搜索出同步点位置的同时,有效估计载波频偏,且计算复杂度显著下降。在动态环境中,载波多普勒频移变化剧烈,普通接收机跟踪环容易失锁,该文提出了一种基于经验值查表的载波跟踪算法,在锁频环内引入经验值查找表,环路能自适应调整滤波器带宽,任意时刻都能保证高精度跟踪。仿真实验表明,当输入信噪比高于-35 dB,载波初始多普勒频偏在12.8 kHz以内,机动载体相对于卫星转发器的径向加速度为5 m/s2(等效多普勒频移变化速度为180 Hz/s),无人机载软件接收机可以进行稳定的数据传输。Abstract: To ensure the reliability of the data transmitting for the Unmanned Aerial Vehicles (UAVs) in dynamic environment, a novel class of fast acquisition algorithm based on Partial Matched Filters and Two-Leveled FFT(PMF-TLFFT) is proposed, which is capable of searching for the code synchronization point as well as estimating the carrier-frequency offset for correction. However, in dynamic environment, as the UAVs usually possesses a larger axial acceleration compared with that of the satellite repeater, the Doppler frequency shifts dramatically, making the tracking loop of a general receiver out of balance. Therefore, An FPLL based on Look-Up Tables (LUT-FPLL) is presented, which employs a list of experiential values in FLL and the bandwidth of the loop filter in FLL is adaptively adjusted, this ensures the high precision tracking performance. Simulation results demonstrate that with the input SNR higher than -35 dB, initial carrier-frequency offset ranging from -12.8 kHz to +12.8 kHz and axial acceleration 5 m/s2 the receiver on the UAVs can efficiently and reliably work.
-
Leitgeb E, Zettl K, and Sheikh M S, et al.. Investigation infree space optical communication links between UnmannedAerial Vehicles (UAVs) [C]. International Conference onTransparent Optical Networks, Rome, Italy, 2007: 152-155.[2]金石, 张晓林, 周琪. 无人机通信信道的统计模型[J]. 航空学报, 2005, 25(1): 62-65.Jin Shi, Zhang Xiao-lin, and Zhou Qi. A statistical model forthe UAV communication channel[J]. Acta Aeronautica etAstronautica Sinica, 2005, 25(1): 62-65.[3]Fazel K and Kaiser S. Multi-carrier and Spread SpectrumSystems[M]. England: Wiley, 2003: 10-55.[4]Sascha M, Scott S I, and Mclaughlin S. An FFT-basedapproach for fast acquisition in spread spectrumcommunication systems[J].Wireless PersonalCommunications.2000, 13(1):27-55[5]Saarnisaari H and Karami E. Frequency domain blockfiltering GNSS receivers[C]. Position Location andNavigation Symposium, Monterey, CA, USA. 2008: 159-166.[6]Vilnrotter V A, Hinedi S, and Kumar R. Frequencyestimation techniques for high dynamic trajectories [J].IEEETransactions on Aerospace and Electronic Systems.1989,25(4):559-577[7]Mao Wei-lung, Tsao Hen-wai, and Chang Fan-ren. A newfuzzy bandwidth carrier recovery system in GPS for robustphase tracking[J].IEEE Signal Processing Letters.2004,11(4):431-434
