浸没流多透镜多注电子光学系统的模拟研究

张瑞; 王勇; 谢敬新

doi:10.3724/SP.J.1146.2008.00799

浸没流多透镜多注电子光学系统的模拟研究

doi: 10.3724/SP.J.1146.2008.00799

计量
- 文章访问数: 3681
- HTML全文浏览量: 105
- PDF下载量: 797
- 被引次数: 0
出版历程
- 收稿日期: 2008-06-23
- 修回日期: 2009-03-11
- 刊出日期: 2009-07-19

Simulation Study of the Confined-Flow Multi-lenses Multi-beam Electron-Optical System

摘要

摘要: 该文采用先2维后3维的计算方法，对L波段高峰值功率多注速调管电子光学系统进行了模拟设计。采用均匀场浸没流多透镜聚焦系统对电子注进行聚焦，获得了通过率100%，填充因子55%，特性良好的旁轴电子注。模拟计算表明，多透镜系统可有效调整电子注平衡半径，电子枪区均匀场可有效调整电子注波动性及层流性，聚集系统可在阴极磁感应强度为0.001~0.01 T，主磁场为0.06~0.13 T的范围内实现对旁轴电子注的良好聚焦。
- 电子光学系统;多注速调管;电子枪;电子注
Abstract: The electron-optical system of an L-band multi-beam klystron is designed. The 2-D simulation for the system is conducted first and the 3-D simulation is done in succession. Confined-flow uniform magnetic fields focusing system with multi-lenses is adopted and the paraxial beams with perfect characteristic are obtained. Simulation indicates that the beam occupancy rate is about 55%, the beam transmission rate is 100%, the multi-lenses system can modulate the beam equilibrium radius effectively and the uniform magnetic field in gun region can modulate the beam trajectories. The focusing system allows matching beams with the magnetic fields on the cathode range from 0.001 T to 0.01 T and the magnetic fields in main region range from 0.06 T to 0.13 T.

HTML全文

参考文献(1)

王勇, 丁耀根, 刘璞鲲, 等. 高峰值功率多注速调管的初步研究[J]. 强激光与粒子束, 2005, 17(8): 1133-1136.Wang Y, and Ding Y G, Liu P K, et al.. Research on highpeak power multi beam klystron[J]. High Power Laser andParticle Beams, 2005, 17(8): 1133-1136.[2]丁耀根, 阮存军, 沈斌, 等. X 波段同轴腔多注速调管的研究[J]. 电子学报, 2006, 34(12): 2337-2341.Ding Y G, Ruan C J, and Shen B, et al.. Study of a X-bandcoaxial cavity multi beam klystron[J]. Acta ElectronicaSinica, 2006, 34(12): 2337-2341.[3]张瑞, 王勇. 高峰值功率多注速调管的发展现状[J]. 真空电子技术, 2007, 3: 25-30.Zhang R and Wang Y. Development of High Peak PowerMulti-Beam Klystron[J]. Vacuum electronics, 2007, 3: 25-30.[4]沈斌, 丁耀根, and Aleksandr N. Sandalov. 超宽带多注速调管的模拟研究[J].电子与信息学报, 2006, 28(1): 180-184.Shen B, Ding Y G, and Aleksandr N. Sandalov. Theoretical,investigations of the super broadband multiple beam klystronamplifier[J]. Journal of Electronics Information Technology,2006, 28(1): 180-184.[5]孙鹏, 丁耀根, 赵鼎. X 波段高峰值功率速调管功率合成器设计[J]. 强激光与粒子束, 2007, 19(11): 1865-1868.Sun P, Ding Y G, and Zhao D. Design of power combiner forX-band high power klystron[J]. High Power Laser andParticle Beams, 2007, 19(11): 1865-1868.[6]丁耀根. 多注速调管电子光学系统的研究[J]. 电子科学学刊,2000, 22(3): 485-491.Ding Y G. Research of the optical system of the multi-beamklystron[J]. Journal of Electronics, 2000, 22(3): 485-491.[7]Gelvich E A, Borisov L M, and Zhary E V, et al.. The newgeneration of high-power multiple-beam klystrons [J].IEEETransactions on Microwave Theory and Techniques.1993,41(1):15-19[8]Korolyov A N, Gelvich E A, and Zhary E V, et al.. Multiplebeamklystron amplifiers: Performance parameters anddevelopment trends[J].IEEE Transactions on PlasmaScience.2004, 32(3):1109-1117[9]张瑞, 王勇. 高峰值功率多注速调管电子光学系统的研究[J].强激光与粒子束, 2006, 18(9): 1519-1523.Zhang R and Wang Y. Electro-optical system in high peakpower multi-beam klystron[J]. High Power Laser and ParticleBeams, 2006, 18(9): 1519-1523.[10]Petillo J J, Eppley K, and Panagos D, et al.. The MICHELLEthree-dimensional electron gun and collector modelingtool:theory and design[J]. IEEE Transactions on PlasmaScience, 2005, 30(3): 1238-1264.[11]Vaughan J R M. Synthesis of the Pierce gun[J].IEEETransactions on Electron Devices.1981, 28(1):37-41
