损耗介质加载结构Ka波段TE01模回旋行波管放大器稳定性的分析

纵啸宇; 薛谦忠; 杜朝海

doi:10.3724/SP.J.1146.2008.00783

损耗介质加载结构Ka波段TE01模回旋行波管放大器稳定性的分析

doi: 10.3724/SP.J.1146.2008.00783

纵啸宇^{①②;薛谦忠},
薛谦忠,
杜朝海

基金项目:

国家自然科学基金(60871051，60871054和60571039)资助课题

计量
- 文章访问数: 3725
- HTML全文浏览量: 111
- PDF下载量: 749
- 被引次数: 0
出版历程
- 收稿日期: 2008-06-19
- 修回日期: 1900-01-01
- 刊出日期: 2009-06-19

Stability Analysis of Ka-band TE01-mode Gyrotron Traveling Wave Amplifier with Lossy Dielectric-Load Waveguide

Zong Xiao-yu^{①②;薛谦忠},
Xue Qian-zhong,
Du Chao-hai

摘要

摘要: 该文从分析损耗介质加载金属圆波导中电磁波传输特性出发，应用回旋行波管放大器小信号色散方程，研究损耗介质加载结构TE01模回旋行波管放大器绝对不稳定性振荡和回旋返波振荡对器件稳定性的影响。结果表明：损耗介质的加载，可以提高绝对不稳定性起振电流，提高的幅度依赖于工作磁场偏离饱和磁场的程度、电子束横纵速度比等；增加波导损耗介质加载的厚度，可以提高竞争模式的回旋返波起振长度。合理选择波导的损耗层厚度、介电常数以及回旋行波管的工作电压、工作磁场和电子束横纵速度比，可以有效兼顾带宽和抑制不稳定性，保证回旋行波管放大器稳定工作。
- 回旋行波管放大器; 损耗介质加载; 稳定性
Abstract: This paper, with the analysis of the propagation characteristics in a lossy cylindrical waveguide and using small-signal theoretical dispersion relation, presents study on the device stability with influence of the absolute instability and the backward wave oscillation in TE01-mode lossy dielectric-load gyrotron traveling wave amplifier. The numerical results show that lossy dielectric-load can heighten the start oscillation current of absolute instability, and increase depends on the magnetic field strength and the perpendicular-to-parallel velocity ratio of the electrons; The thickness of the lossy waveguide increases the start oscillation length of backward wave oscillation. The combined appropriate selection of the lossy waveguide thickness, permittivity, voltage, the applied magnetic field and the velocity ratio can effectively give attention to bandwith and instability to ensure the stable operation of the gyrotron traveling wave amplifier.

HTML全文

参考文献(1)

Chu K R and Lin A T. Gain and bandwidth of the gyro-TWTand CARM amplifiers[J].IEEE Trans. on Plasma Science.1988,16(2):90-104[2]张克潜, 李德杰. 微波与光电子学中的电磁理论[M](第二版),北京: 电子工业出版社, 2001: 266-271.Zhang K Q and Li D J. Electromagnetic Theory forMicrowave and Optoelectronics[M]. 2nd edition, Beijing:Electronics Industry Press, 2001: 266-271.[3]焦重庆. 回旋行波管放大器的相关理论和数值模拟[D]. [博士论文], 中国科学院电子学研究所, 2006: 16-70.Jiao C Q. Theoretical study and numerical simulation of thegyrotron traveling wave amplifier [D]. [Ph.D. dissertation],Institute of Electronics, Chinese Academy of Sciences, 2006:16-70.[4]Kou C S, Wang Q S, McDermott D B, and Lin A T, et al..High-power harmonic Gyro-TWTspart I: linear theoryand oscillation study[J].IEEE Trans. on Plasma.1992, 20(3):155-162[5]Rao S J, Jain P K, and Basu B N. Broadbanding of aGyro-TWT by dielectric-loading through dispersion shaping[J].IEEE Trans. on Electron Devices.1996, 43(12):2290-2298[6]薛谦忠, 纵啸宇, 邹峰, 刘濮鲲. 具有分布损耗波导结构的回旋行波放大器绝对不稳定性[J]. 强激光与粒子束, 2008, 20(2):263-267.Xue Q Z, Zong X Y, Zou F, and Liu P K. Absolute instabilityin gyrotron traveling wave amplifier with distributed losswaveguide[J]. High Power and Particle Beams, 2008, 20(2):263-267.[7]焦重庆, 罗积润. 有损金属圆波导中电磁波传输特性的研究[J]. 物理学报, 2006, 55(12): 6360-6367.Jiao C Q and Luo J R. Propagation of electromagnetic wavein a lossy cylindrical waveguide [J]. Acta Phy. Sin. 2006,55(12): 6360-6367.[8]Du C H, Xue Q Z, and Liu P K. Loss-induced modeltransition in a dielectric-coated metal cylindrical waveguidefor Gyro-Traveling-Wave-Tube applications. IEEE ElectronDevice Letters, 2008, 29 (11): 346-349.[9]Kou C S. Starting oscillation conditions for gyrotronbackward wave oscillators[J].Phys. Plasmas.1994, 1(9):3093-3099
