TM310模的同轴谐振腔与波导孔耦合及场分布研究
doi: 10.3724/SP.J.1146.2007.01875
Research on Field Distribution of TM310 Mode in Cylindrical Coaxial Cavity Resonator with Coupling of Waveguide Hole
-
摘要: 该文研究了采用TM310高阶模同轴谐振腔与波导孔耦合构成的多注速调管输出回路。从理论上阐述了调节该输出腔的外观品质因数的原理和方法，并利用三维电磁场软件CST进行了模拟验证，得到TM310模场分布均匀的，具有较低外观品质因数的同轴输出腔。Abstract: Output circuit of multi-beam klystron, which is consist of coaxial cavity with high-order mode of TM310 and coupling of waveguide hole, is analyzed in this article. Some methods and steps of adjusting external Q-factor of cavity are described in theory. Some simulations are also made using CST MicroWave Studio (MWS). Output cavity with symmetrical field distribution of TM310 mode and low external Q-factor is obtained in this article.
-
