新型高导热螺旋线慢波结构的设计和仿真分析
doi: 10.3724/SP.J.1146.2007.01761
Design and Simulation Analysis of Novel Helical Slow-wave Structure with High Heat Transfer
-
摘要: 该文从理论上通过对螺旋线慢波结构的热状态进行分析，首次提出以椭圆管壳结构来代替传统的圆管壳结构，然后利用ANSYS软件对椭圆管壳螺旋线慢波结构作了三维热分析并利用微波工作室CST分析了其高频特性。仿真结果表明，椭圆管壳螺旋线慢波结构的导热能力明显强于传统的圆壳结构，且夹持杆数目越多，导热能力越强。同时还发现椭圆管壳慢波结构在保证足够大耦合阻抗前提下，其工作带宽相对圆壳更宽。
-
关键词:
- 行波管;螺旋线慢波结构;椭圆管壳;热分析
Abstract: The thermal statement of the helical slow wave structure is analyzed in detail in this paper, and an elliptical shell is firstly brought up to replace the conventional circle shell in the slow-wave structure. Then the 3D thermal analysis of the helical slow structure with elliptical shell is done with the help of ANSYS and the high-frequency characteristics simulation is also done with WMS CST. It is demonstrated that the ability of heat transfer of the helical slow structure with elliptical shell is much better than the conventional one and the more the support rods are, the better the heat transfer is. It is also found that the bandwidth of the elliptical shell is more wider than the circle one while the coupling impedance just decrease a little. -
国防科工委军用标准化中心. 电子设备可靠性热设计手册实施指南[M]. 北京, 国防工业出版社, 1992.[2]丁耀根. 大功率微波电真空器件的发展动向[J]. 真空电子技术, 2006, 3: 37-40.Ding Yao-gen. The trend of high power microwave vacuumdevices [J]. Vacuum Electronics, 2006, 3: 37-40.[3]Barker R J, Booske J H, and Luhmann Jr N C, et al.. ModernMicrowave and Millimeter-wave Power Electronics [M]. IEEEPress, New York, 2005: Ch.4.[4]Harper R and Puri M P. Heat transfer and power capabilitiesof EHF helix TWTs [C]. International Electron DevicesMeeting, Washington, DC, 1986: 498-500.[5]Han Yong, Liu YanWen, and Ding YaoGen, et al.. Anevaluation of heat dissipation capability of slow wavestructures [J].IEEE Trans. on Electron Devices.2007, 54(6):1562-1565[6]Lie Ming Yao, Zhong Hai Yang, and Bin Li, et al.. Thermalanalysis of novel helix TWTs [C]. IEEE InternationalVacuum Electronics Conference, Monterey, California, 2006:139-140.[7]赵兴群, 张国兴, 孙小菡等. 脉冲螺线行波管热状态分析及ANSYS 模拟[J]. 电子学报, 2004, 32(6): 1029-1032.Zhao Xing-qun, Zhang Guo-xing, and Sun Xiao-han, et al..The analysis and ANSYS simulation for the thermalcondition of pulse helix TWT [J]. Acta Electronica Sinica,2004, 32(6): 1029-1032. -
