SNR估计误差对BICM-ID系统性能影响的研究

邹雪兰; 酆广增

doi:10.3724/SP.J.1146.2007.01231

SNR估计误差对BICM-ID系统性能影响的研究

doi: 10.3724/SP.J.1146.2007.01231

基金项目:

国家自然科学基金(60472104)资助课题

计量
- 文章访问数: 3641
- HTML全文浏览量: 77
- PDF下载量: 905
- 被引次数: 0
出版历程
- 收稿日期: 2007-07-25
- 修回日期: 2007-12-12
- 刊出日期: 2008-05-19

Study of the Performance Sensitivity to SNR Mismatch in BICM-ID System

摘要

摘要: 在BICM-ID(Bit-Interleaved Coded Modulation with Iterative Decoding,BICM-ID)系统或其他级联码系统中实现迭代检测接收机需要对信道的信噪比(SNR)进行估计。该文研究信噪比估计误差对BICM-ID系统性能的影响,分析各种译码算法对信噪比估计误差的敏感程度。理论分析和仿真结果表明max-log-APP算法对信噪比估计具有最好的鲁棒性,log-APP及其他简化算法对SNR估计误差的鲁棒性在SNR过估计时比SNR欠估计时好,原因在于各个算法所采用的修正函数不同。满足算法性能没有大的损失的SNR估计误差精度范围随着信道条件的改善而增大,通常在-2dB到+6dB之间。因此在非理想的信道状态信息条件下,max-log-APP算法是BICM-ID系统的最佳译码算法。
- 迭代检测; SNR估计误差; 软输入软输出算法; BICM-ID
Abstract: The iterative decoding schemes such as BICM-ID and other concatenated coding systems require the knowledge of channel Signal-to-Noise Ratio (SNR). The effect of SNR estimation errors is studied for BICM-ID in the paper and the performance sensitivity of SNR mismatch for the log-APP decoding algorithm and its simplified implementations is analyzed. Analysis and simulation results show that the max-log-APP algorithm is robust against any SNR mismatch problem, while the log-APP algorithm and other simplified implementations are more tolerant of overestimation of SNR than underestimation, which is because they use different correction functions. The required SNR accuracy to prevent large performance degradation is increased with the increase of channel SNR, generally from -2dB to +6dB. Therefore, when there is no perfect channel state information, the max-log-APP algorithm is the optimum decoding algorithm for BICM-ID.

HTML全文

参考文献(1)

Li X, Chindapol A, and Ritcey J A. Bit-interleaved codedmodulation with iterative decoding and 8PSK signaling[J].IEEE Trans. on Commun.2002, 50(8):1250-1257[2]Chindapol A and Ritcey J A. Design, analysis, andperformance evaluation for BICM-ID with square QAMconstellations in Rayleigh fading channels[J].IEEE Journal onSelected Areas in Communications.2001, 19(5):944-957[3]Jordan M A and Michols R A. The effects of channelcharacterization on turbo code performance[J].Proc. Milcom96,McLean, VA, Oct.1996, 1:17-21[4]Summer T A and Wilson S G. SNR mismatch and onlineestimation in turbo decoding[J].IEEE Trans. on Commun.1998, 46(4):421-423[5]Cheng J F and Ottosson T. Linearly approximated log-MAPalgorithms for Turbo coding. Proc. IEEE Veh. Tech. Conf.(VTC), Houston, TX, May 2000: 2252-2256.[6]Zhou Z D and Vucetic B. Adaptive bit-interleaved codedmodulation in MIMO systems using outdated CSI[J].IEEEICC06, Istanbul, Turkey, June.2006, 11:5028-5033[7]Tran N H, Nguyes H H, and Le-Ngoc T. Bit-interleaved codedOFDM with signal space diversity: subcarrier grouping androtation matrix design[J].IEEE Trans. on Signal Processing.2007, 55(3):1137-1149[8]Djordjevic I B, Cvijetic M, and Xu L, et al.. Proposal forbeyond 100-Gb/s optical transmission based on bitinterleavedLDPC-coded modulation[J].IEEE PhotonicsTechnology Lett.2007, 19(12):874-876[9]Robertson P, Villebrun E, and Hoeher P. A comparison ofoptimal and sub-optimal MAP decoding algorithmsoperating in the log domain[J].Proc. IEEE Int. Conf.Commun. 95 (ICC95), Seattle, USA, June.1995, 2:1009-1013[10]Gross W J and Gulak P G. Simplified MAP algorithmsuitable for implementation of turbo decoders. ElectronicsLett., 1998, 34(16): 1577-1578.[11]Zou X L and Feng G Z. A modified max-log-MAP algorithmfor turbo decoding. Journal of China University of Posts andTelecommunications, 2002, 9(1): 7-12.[12]Benedetto S, Divsalar D, and Monrorsi G, et al.. A soft-inputsoft-output APP modules for iterative decoding ofconcatenated codes[J].IEEE Commun. Letters.1997, 1(1):22-24[13]Schreckenbach F, Gortz N, and Hagenauer J, et al..Optimization of symbol mappings for bit-interleaved codedmodulation with iterative decoding[J].IEEE Commun. Lett.2003, 7(12):593-595[14]Viterbi A J. An intuitive justification and a simplifiedimplementation of the MAP decoder for convolutional codes[J].IEEE Journal on Selected Areas in Communications.1998, 16(2):260-264
