合成孔径雷达成像中频带分割与子带处理技术研究

宋岳鹏; 柳祥乐; 杨汝良

doi:10.3724/SP.J.1146.2007.01181

合成孔径雷达成像中频带分割与子带处理技术研究

doi: 10.3724/SP.J.1146.2007.01181

宋岳鹏^{①②;柳祥乐},
柳祥乐,
杨汝良

计量
- 文章访问数: 3008
- HTML全文浏览量: 95
- PDF下载量: 1139
- 被引次数: 0
出版历程
- 收稿日期: 2007-07-16
- 修回日期: 2007-10-29
- 刊出日期: 2009-01-19

Study on Intersection of Spectrum and Sub-band Processing Technique in Synthetic Aperture Radar Imaging

摘要

摘要: 采用多收多发孔径的合成孔径雷达(SAR)可以获得较常规SAR更宽的测绘带和更高的空间分辨率。该文将频带分割技术应用到多收多发孔径SAR成像中，在实现方位向高分辨率的同时获得距离向高分辨率。针对同步收发的子带脉冲信号，提出了一种时域先合成再脉冲压缩的方法，并对频域子带先脉冲压缩再合成的方法进行了扩展，提出了非零中频子带脉冲压缩合成的方法，仿真结果证明了方法的有效性。文中研究了子带载频差对压缩结果及成像的影响，并通过计算机仿真分别对两种相位差的影响进行了说明。
- SAR;频带分割;子带合成;宽测绘带
Abstract: Synthetic Aperture Radar (SAR) using multiple transmit-receive apertures can obtain wider swath and higher spatial resolution. In this paper, intersection of frequency spectrum is adopted in the SAR imaging using multiple transmit-receive apertures, which can achieve high range and azimuth resolution simultaneously. As for sub-band pulses synchronously transmit-received, a method of sub-band combination in time domain prior to pulse-compression is proposed and sub-band compression prior to combining is proposed in frequency domain as a extension. The simulation result illustrates the validity of these methods. In addition, there exist some phase differences caused by the carrier frequency and their influence on pulse compression and SAR imaging is studied, the computer simulation is made to show the influence.

HTML全文

参考文献(1)

Currie A and Brown M A. Wide-swath SAR. IEEProceedings-Radar Sonar and Navigation, 1992, 139(2):122-135.[2]Song Yuepeng and Yang Ruliang. High resolution, wideswath SAR using sub-aperture sub-band technique.Proceedings of CIE international conference on radar,Shanghai, China, 2006: 1298-1301.[3]李海英. 超宽带信号波形及合成孔径雷达成像研究. [博士论文], 中国科学院电子学研究所, 2002.[4]Daniel Rabinkin and Truong Nguyen. Optimum subbandfilterbank design for radar array signal processing with pulsecompression. Sensor Array and Multichannel SignalProcessing Workshop. Proceedings of the 2000 IEEE,Cambridge, Massachusetts., USA, 2000: 315-321.[5]Rabinkin D and Pulsone N. Subband-domain signalprocessing for radar array systems[J].Proc. SPIE.1999, Vol.3807:174-187[6]水鹏朗, 保铮. 基于频带分割的超宽带雷达脉冲压缩方法. 电子学报, 1999, 27(6): 50-53.[7]杨延光, 黄晓涛. 基于匹配滤波和频带分割的超宽带信号脉冲压缩方法. 雷达科学与技术, 2005, 3(6): 361-366.[8]Zhang Yimin. Adaptive array processing for multipath fadingmitigation via exploitation of filter banks[J].IEEE Trans. onAntennas and Propagation.2001, 49(4):505-516[9]Zatman Michael. How narrow is narrowband? IEEEProceedings: Radar, Sonar, and Navigation, 1998, 145(2):85-91.[10]Weiss L G. Wavelets and wideband correlation processing[J].IEEE Signal Processing Magazine.1994, 11(1):13-32[11]Hoffman A and Kogon S M. Subband STAP in widebandradar systems. Proceedings of IEEE on sensor array andmultichannnel signal processing, Cambridge, Massachusetts.USA, 2000: 256-260.[12]Song Yuepeng and Yang Ruliang. High resolution.[J].wideswath synthetic aperture radar using multipletransmit-receive aperture. EUSAR06, Dresden, Germany,May 16-1.2006,:-
