非移变模式机载双基地SAR成像算法及实验结果
doi: 10.3724/SP.J.1146.2007.01066
Translationally Invariant Airborne Bistatic SAR Imaging Algorithm and Experimental Result
-
摘要: 该文通过对机载双基地SAR非移变几何模型的分析，建立了双距离变量域的回波信号模型，由于回波数据是在距离和域，该文推导了距离和变量与双距离变量的转换关系，解决了该模型向距离和变量域转换的问题；提出了适用于非移变模式的变多普勒参数的双基地RD算法，并对该算法中引入变多普勒斜率所存在的误差进行了仿真分析。最后通过双基SAR仿真及实测数据处理，证实了算法的有效性，并与常规RD算法进行了比较，显示了该方法的优越性。Abstract: Based on the analysis of bistatic SAR geometry model, bistatic SAR echoed signal is modeled in the double range variables domain in this paper, and the relationship between the double range variable domain and the single range variable domain is established. Then a range-dependent Doppler algorithm for imaging processing airborne bistatic SAR raw data of the translationally invariant configuration is derived, and the effect of error of the algorithm is analyzed by simulating. The algorithm is also tested with real data, and the advantage of the algorithm is proved by the comparison with bistatic SAR traditional RD algorithm.
-
Ender J H, Walterscheid I, and Brenner A. New aspects ofbistatic SAR: processing and experiments. Proc, IGARSS,Anchorage, US, Sep, 2004: 1758-1762.[2]Walterscheid I and Ender J H. Bistatic SAR processing andexperiments[J].IEEE Trans. on Geosci. Remote Sensing.2006,44(10):2710-2717[3]Loffeld O, Nies H, Peters V, and Knedlik S. Models anduseful relations for bistatic SAR processing[J].IEEE Trans. onGeosci. Remote Sensing.2004, 42(10):2031-2038[4]Yates G, A Horne M, Blake A P, Middleton R, and Andre DB. Bistatic SAR image formation. Proc. EUSAR, Ulm,Germany, May 2004: 581-584.[5]Xia Xiang-Gen. Discrete Chirp-Fourier Transform and itsapplication to chip rate estimation. IEEE Trans. on SignalProcessing, 2000, 48(11): 3123-3133. -
