含源-负载交叉耦合的准椭圆函数滤波器设计
doi: 10.3724/SP.J.1146.2007.00409
Design of Quasi-Elliptic Filter with Source-Load Cross-Coupling
-
摘要: 该文首先提出了含源-负载交叉耦合滤波器的等效网络模型,并给出了这种结构的传输函数t(s)以及矩阵的综合方法。由含源-负载交叉耦合二端口网络的短路导纳矩阵推导了耦合矩阵M中MSL、MSi和MiL的一般表达式。最后,设计了一种新颖结构的含源-负载交叉耦合的微带滤波器,对其进行了仿真与制作,实测结果与仿真值、理论值吻合较好。Abstract: A general method is presented for synthesis of quasi-elliptic filter with source-load coupling. The equivalent circuit of the low-pass prototype of a lossless coupled resonator filter is proposed, as well as its transfer function t (s ).The expressions of MSL, MSi and MiL in the coupling matrix M are obtained based on two-port admittance matrix [ YN ]. Finally, a novel quasi-elliptic two pole microstrip filter composed of two hexagonal open-loop resonators is designed. The numerical results are verified with the simulation, The measured and simulated data are in good agreement.
-
Cameron R J. General coupling matrix synthesis methods forChebyshev filtering function[J].IEEE Trans. on MicrowaveTheory Tech.1999, 47(4):433-442[2]Atia A E and Williams A E. Narrow bandpass waveguide filters[J].IEEE Trans. on Microwave Theory Tech.1972, 20(4):258-265[3]Amari S. Synthesis of cross-coupled resonator filters using ananalytical gradient-based optimization technique[J].IEEETrans. on Microwave Theory Tech.2000, 48(9):1559-1564[4]Amari S and Bornemann J. Maximum number of finitetransmission zeros of coupling resonator filters with source/load multi-resonator coupling and a given topology.Asia-Pacific Microw ave Conference, Sydney, Australia, 2000AP 3-6: 1175-1177.[5]Kolmakov Y A, Savino A M, and Vendik I B. Quasi-elliptictwo pole microstrip filter. 15th International Microwaves,Radar and Wireless Communications Conference, Warsaw,Poland. 2004, 1:159-161.[6]Montejo-Garai J R. Synthesis of n-even order symmetricfilters with N transmission zeros by means of source-loadcross coupling[J].Electron. Lett.2000, 36(3):232-233[7]Amari S and Rosenberg U. Adaptive synthesis and design ofresonator filter a with source/load multi-resonator coupling[J].IEEE Trans. on Microwave Theory Tech.2002, 50(8):1969-1978[8]梁昌洪. 计算微波. 西安：西北电讯工程学院出版社, 1985:218-246.[9]Cameron R J. Advanced coupling matrix synthesistechniques for microwave filters[J].IEEE Trans. on MicrowaveTheory Tech.2003, 51(1):1-10[10]Amari S. Direct synthesis of folded symmetric resonatorfilters with source- load coupling[J].IEEE Microwave andWireless Components Letters.2001, 11(6):264-266 -
