星机双基地SAR二维频谱解析表达式求解方法研究

刘喆; 杨建宇; 张晓玲; 皮亦鸣

doi:10.3724/SP.J.1146.2007.00297

星机双基地SAR二维频谱解析表达式求解方法研究

doi: 10.3724/SP.J.1146.2007.00297

计量
- 文章访问数: 3069
- HTML全文浏览量: 108
- PDF下载量: 1059
- 被引次数: 0
出版历程
- 收稿日期: 2007-02-26
- 修回日期: 2007-07-27
- 刊出日期: 2008-09-19

Solution for Two-Dimensional Spectrum Analytical Expression of Spaceborne/Airborne Hybrid BSAR

摘要

摘要: 二维频谱解析表达式是SAR系统频域成像算法的关键所在。针对难以直接求解星机双基地SAR系统驻定相位时间点的解析解的问题，该文提出对系统响应二维频谱的相位项在一个易于求得解析解的时间点做二阶泰勒展开并取近似；利用该系统两平台间运动速度、斜距差异显著的特点，来选取泰勒展开时间点，使其位于系统驻定相位时间点满足一定条件的邻域内，从而保证了近似相位的误差可忽略，由此获得较精确的近似二维频谱及其解析表达式。文中分别利用TerraSAR-X和PAMIR作为星载、机载平台，仿真成像场景内不同点目标近似二维频谱的相位误差，并利用近似二维频谱对点目标回波进行成像处理仿真，仿真结果验证了本文方法的有效性。
- 星机双基地SAR /
- 二维频谱 /
- 解析表达式
Abstract: Two-dimensional spectrums analytical expression is the basis of the frequency domain imaging algorithm for SAR system. A solution for the approximated two-dimensional spectrums analytical expression of spaceborne/airborne hybrid BSAR is presented. To overcome the difficulty of resolving analytical solution for the systems stationary phase point, the two-dimensional spectrums phase is two-order expanded around the point, which is not only in the neighborhood of the systems corresponding stationary phase point but also can be obtained analytically. Thus the spaceborne/airborne hybrid BSAR system responses approximated spectrum is pretty close to the real one and can be expressed analytically. Taking TerraSAR-X as transmitter and PAMIR as receiver, the phase error caused by the approximation is simulated for different point targets in the image scene, and the simulated echo of point target is focused by the approximated two-dimensional spectrum. The simulation results demonstrate the validity of the proposed solution.
- S /
- p

HTML全文

参考文献(1)

[1] Keydel W. Perspectives and visions for future SARsystems[J].IEE Proceedings-Radar, Sonar and Navigation.2003, 150(3):97-103 [2] Griffiths H D, Baker C J, and Baubert J, et al.. Bistaticradar using satellite-borne illuminator[C]. RADAR, London,UK, 2002: 1-5. Cherniakov M. Space-surface bistatic synthetic apertureradar . Prospective and problems[C]. InternationalConference of Radar, Edinburgh, UK, 2002: 22-26. [3] DAria D, Guarnieri A M, and Rocca F. Focusing bistaticsynthetic aperture aadar using dip move out[J]. IEEE Trans.on GRS, 2004, 42(7): 1362-1375. [4] Ender J H G. A step to bistatic SAR processing[C]. EUSAR,Germany, 2004: 359-364. [5] 何峰, 梁甸农，董臻. 适于大斜视角的星载双基地SAR 波数域成像算法[J]. 电子学报, 2005, 33(6): 1011-1014.He Feng, Liang Dian-nong, and Dong Zhen. A wavenumberdomain algorithm for spaceborne bistatic SAR imaging withlarge squint angle[J]. Acta Electronica Sinica, 2005, 33(6):1011-1014. [6] Verdent G, Huber C, and Franck D. An Omega-K algorithmfor SAR bistatic systems[C]. IGARSS, Korea, 2005:1060-1063. [7] Natroshvili K, Loffeld O, and Nies H. Focusing of generalbistatic SAR configuration data with 2-D inverse scaledFFT[J]. IEEE Trans. on GRS, 2006, 44(10): 2718-2727. [8] Bamler R. A comparision of range-doppler and wavenumberdomain SAR focusing alogorithms[J]. IEEE Trans. on GRS,1992, 30(4): 703-713. [9] Lanari R. A new method for the compensation of the SARrange cell migration based on the chirp Z-transform[J]. IEEETrans. on GRS, 1995, 33(5): 1296-1299. [10] 刘喆，杨建宇，皮亦鸣等. 基于相位近似的双基地SAR 波数域成像算法[J]，电子与信息学报，2007, 29(9): 2094-2097Liu Zhe, Yang Jian-yu, and Pi Yi-ming, et al.. A wavenumberdomain imaging algorithm for bistatic SAR system based onphase approximation [J].. Journal of Electronics Information Technology.2007, 29(9):2094-2097 [11] Loffeld O, Nies H, and Peters V, et al.. Models and usefulrelations for bistatic SAR processing[J]. IEEE Trans. onGRS, 2004, 42(10): 2031-2038. [12] Gebhardt U, Loffeld O, and Nies H. Bistatic airborne/spaceborne hybrid experiment: basic considerations [C].SPIE International Symposium on Remote Sensing, Belgium,2005, Vol. 5978: M-1-M-10. [13] Neo Y L, Wong F, and Cumming I G. A two-dimensionalspectrum for bistatic SAR processing using seriesreversion[J]. IEEE GRS Letters, 2007, 4(1): 93-96.
