一种新型的回旋管用多波导输出系统
doi: 10.3724/SP.J.1146.2007.00217
A New Type of Multi-waveguide Output System for Gyrotron Applications
-
摘要: 该文提出了一种用于回旋管的多波导输出结构。利用 高频计算软件，对这种结构进行了数值模拟，通过对各相关尺寸进行合理选择以及模式转换过程的优化，不仅有效实现了工作模式之间的输出转换，同时在一定程度上降低了竞争模式对工作模式的影响。在Ka波段，获得了对驻波比小于1.5情况下，从TE01○到TE10□模输出能量转换效率大于95.9%和带宽接近 3%的结果。Abstract: In this paper, a multi-waveguide output structure for gyrotron applications is proposed. Numerical simulations are performed for this structure by using High Frequency Structure Simulator ( Ansoft HFSS ). The results show that the energy conversion efficiency of more than 95.9% from the TE01○ mode to the TE10□ mode can be reached with the bandwidth of about 3% at VSWR of less than1.5 for the TE01○ mode input.
-
Kuntze M, Alberti S, and Dammertz G, et al.. Advancedhigh-power gyrotrons[J].IEEE Trans. on Plasma Science.2003,31(1):25-31[2]Granatstein V L, Levush B, and Danly B G, et al.. A quartercentury of gyrotron research and development[J].IEEE Trans.on Plasma Science.1997, 25(6):1322-1335[3]Ogawa I, Idehara T, and Itakura Y, et al.. Mode conversion ofa gyrotron output into a Gaussian beam for its variousapplications. 2004 Joint 29th Int. Conf. on Infrared andMillimeter waves and 12th Int. Conf. on Terahertz Electronics,Karlsruhe, Germany, September 27-October 1, 2004: 797-798.[4]Yu Ching-Fang and Chang Tsun-Hsu. High-performancecircular TE01-Mode converter[J].IEEE Trans. on MicrowaveTheory and Techniques.2005, 53(12):3794-3798[5]Thumm M. High-power millimeter-wave mode converters inovermoded circular waveguides using periodic wallperturbations[J].International Journal of Electronics.1984,57(6):1225-1246[6]Luan Yuantao, Luo Jirun, and Su Yinong, et al.. Numericalsimulation of a mode converter from TE10 rectangular guidemode to TE01 coaxial guide mode. Proceedins of IVEC2003,Seoul, Korea, 2003, P1. 68-69.[7]McCurdy A H and Choi J J. Design and analysis of a coaxialcoupler for a 35-GHz gyroklystron amplifier[J].IEEE Trans. onMicro. Theory and Tech.1999, 47(2):164-175 -
