一种天波超视距雷达分级Hough变换航迹起始方法

金术玲; 梁彦; 潘泉; 程咏梅

doi:10.3724/SP.J.1146.2006.02033

一种天波超视距雷达分级Hough变换航迹起始方法

doi: 10.3724/SP.J.1146.2006.02033

基金项目:

国家自然科学基金重点项目(60634030)资助课题

计量
- 文章访问数: 3851
- HTML全文浏览量: 104
- PDF下载量: 964
- 被引次数: 0
出版历程
- 收稿日期: 2006-12-25
- 修回日期: 2007-06-25
- 刊出日期: 2008-08-19

A Two-hierarchy Hough Transform Based Track Initiation Method for Sky-wave Over-the-Horizon Radar

摘要

摘要: 天波超视距雷达固有的低数据率、低检测概率和低量测精度等特征对航迹起始方法提出新的挑战。本文提出了一种天波超视距雷达两级Hough变换航迹起始算法(TH-HT)。该方法首先采用时间-径向距离数据进行第1级Hough变换，将多普勒量测作为积累约束条件来避免无效积累，得到候选航迹；之后对与每条候选航迹相应的时间-方位角数据进行第2级Hough变换，最终得到确认航迹。通过描述各级积累单元获得杂波投票数期望的定理，给出两级阈值的确定方法。与MMUPDA的仿真比较表明，TH-HT不但具有较高的航迹起始概率和较低的虚假航迹概率，而且运行时间大大降低。
- 天波超视距雷达; 航迹起始; Hough变换
Abstract: The 3L (low data sampling rate, low measurement precision and low detection probability) features of sky-wave Over-The-Horizon Radar (OTHR) pose new challenges to the conventional track initiation methods. In this paper, a Two-Hierarchy Hough Transform track initiation method (TH-HT) is proposed. Firstly the range-time data space is used to hierarchical I Hough transform and rough candidate tracks are obtained, where Doppler is used as an accumulation constraint; then such rough candidate tracks are further refined by time-azimuth accumulation in hierarchical II Hough transform. Moreover, two theorems concerning the expectation of the number of clutters voting to each cell of each hierarchy are given, which provides a way of determining the two-hierarchy threshold value. In simulation, the proposed method is compared with the classical initiation method of OTHR-MMUPDA. Simulation results show that TH-HT has higher track detection probability and lower false track probability; meanwhile it is much less time-consuming.

HTML全文

参考文献(1)

Pulford G W and La Scalay B F. Over-the-horizon radartracking using the viterbi algorithm. third report to highfrequency radar division. CSSIP Report No.27/95, Dec. 1995.[2]Pulford G W and Evans R J. A multipath data associationtracker for over-the-horizon radar[J].IEEE Trans. onAerospace and Electronic Systems.1998, 34(4):1165-1883[3]Davey S J and Colegrove S B. A unified joint probabilisticdata association filter with multiple models, Technical reportDSTO-TR-1184, Defense Science and Technology Organization,July 2001.[4]Colegrove S B and Davey S J. PDAF with multiple clutterregions and target models[J].IEEE Trans. on Aerospace andElectronic Systems.2003, 39(1):110-124[5]刘慧霞、梁彦、潘泉、程咏梅. 天波超视距雷达多路径Viterbi数据关联跟踪算法. 电子学报, 2006, 34(9): 1640-1644.Liu H X, Liang Y, Pan Q, and Cheng Y M. A multipathviterbi data association algorithm for over-the-horizon-radar.Acta Electronica Sinica, 2006, 34(9):1640-1644.[6]Carlson B D, Evans E D, and Wilson S L. Search radardetection and track with the Hough transform Part I: SystemConcept. IEEE Trans. on AES, 1994, 30(1):102-108.[7]Wilson S L, Carlson B D, and Evans E D. Search radardetection and track with the Hough transform, Part II:Detection statistics. IEEE Trans. on AES, 1994, 30(1):109-115.[8]Evans E D, Wilson S L, and Carlson B D. Search radardetection and track with the Hough transform, Part III:Detection performance with binary integration. IEEE Trans.on AES, 1994, 30(1): 116-125.[9]Yankowich S W and Farooq M. Hough transform basedmultisensor, multitarget, track initiation technique. Opt. Eng1998, 37(7): 2064-2077.[10]王国宏, 苏峰, 毛士艺, 何友. 杂波环境下基于Hough 变换和逻辑的快速航迹起始算法. 系统仿真学报, 2002, 14(7):873-875.Wang G H, Su F. Mao S Y, and He Y. Fast track initiationalgorithm in clutter environments based on HoughTransform and Logic. Acta Simulata Systematica Sinica,2002, 14(7): 873-875.[11]王国宏, 苏峰, 何友. 三维空间中基于Hough 变换和逻辑的航迹起始. 系统仿真学报, 2004, 16(10): 2198-2200.Wang G H, Su F, and He Y. Hough transform (HT) andlogic based track initiator in three dimensional space. ActaSimulata Systematica Sinica, 2004, 16(10): 2198-2200.[12]曲长文, 黄勇, 苏峰, 何友. 基于坐标变换与随机Hough 变换的抛物线运动目标检测算法[J].电子与信息学报.2005, 27(10):1573-1575浏览[13]郭汝江, 袁业术, 权太范. 高频地波雷达飞行小目标跟踪方法研究. 电子学报, 2005, 33(9): 1586-1589.Guo R J, Yuan Y S, and Quan T F. Study of anti-weak aerialtarget tracking for high frequency surface wave radar. ActaElectronica Sinica, 2005,33(9): 1586-1589.[14]Hu Zhijian and Leung Henry. Statistical performanceanalysis of track initiation techniques[J].IEEE Trans. on Signalprocessing.1997, 45(2):445-456
