3mm回旋行波放大器单阳极磁控注入式电子枪的设计

殷瑞剑; 刘濮鲲

doi:10.3724/SP.J.1146.2006.01896

3mm回旋行波放大器单阳极磁控注入式电子枪的设计

doi: 10.3724/SP.J.1146.2006.01896

殷瑞剑^{①②;刘濮鲲},
刘濮鲲

基金项目:

国家自然科学基金(60571039)和国家杰出青年科学基金(60125104)资助课题

计量
- 文章访问数: 3206
- HTML全文浏览量: 100
- PDF下载量: 828
- 被引次数: 0
出版历程
- 收稿日期: 2006-11-29
- 修回日期: 2007-05-17
- 刊出日期: 2008-06-19

Design of a Single-anode Magnetron-injected-gun for the 3mm GYRO-TWT Amplifiers

Yin Rui-jian^{①②;刘濮鲲},
Liu Pu-kun

摘要

摘要: 该文根据3mm回旋行波放大器对电子枪的要求,完成了单阳极磁控注入式电子枪的设计。首先由绝热理论和角动量守恒关系式,求出了电子枪的初始设计参数,如阴极倾角、电子注发射表面宽度和阴-阳极间距离等;然后借助电子注轨迹分析程序EGUN,利用数值计算的方法得到了最终的电子注参数。结果显示:在电子注加速电压70kV,工作电流4.55A,电子注的横向与纵向速度比为1.0时,电子注的轴向速度零散为2.4%,能够满足回旋行波管放大器对电子注低速度零散的要求。
- 回旋行波放大器; 电子枪; 单阳极; 速度零散
Abstract: A single-anode electron gun is designed and simulated according to the requirements of the gyrotron traveling wave amplifier. Firstly，the initial parameters for example the cathode angle, the cathode emitter strip and the distance between cathode and mod-anode are designed based on analytic trade-off equations. Secondly，the final beam parameters are determined with the electron trajectory code EGUN. The results reveal that when the accelerated voltage is 70kV and the beam current is 4.55A, electron gun has the axial velocity spread of 2.4%, and the ratio of the transverse velocity to the axial velocity is equal to 1.0, which can satisfy the requirement of the low electron beam velocity spread in the gyrotron traveling wave amplifier.

HTML全文

参考文献(1)

刘濮鲲, 徐寿喜. 回旋速调管放大器及其发展评述[J].电子与信息学报.2003, 25(5):683-694浏览[2]Kevin L F, Bruce G D, and Howard R J, et al..Characteristics and applications of fast-wave gyrodevices[J].Proc. IEEE.1999, 87(5):752-781[3]Chu K R. The electron cyclotron maser. Reviews of ModernPhysics, 2004, 76: 489-540.[4]Chu K R. Overview of research on the gyrotrontraveling-wave amplifier[J].IEEE Trans. Plasma Science.2002,30(3):903-908[5]Chu K R. Ultra-high gain gyrotron traveling wave amplifier[J].Phys. Rev. Lett.1998, 81(21):4760-4763[6]Leon K C, McDermott D B, and Balkum A J, et al.. Stablehigh power TE01 gyro-TWT amplifiers[J].IEEE Trans. PlasmaScience.1994, 22(5):585-592[7]Wang Q S, McDermott D B, and Luhmann N C, et al..Operation of a stable 200-kW second harmonics Gyro-TWTamplifier[J].IEEE Trans. on Plasma Science.1996, 24(3):700-706[8]贾云峰, 来国军, 刘濮鲲. Ka 波段基波回旋行波管放大器的模拟与设计. 红外与毫米波学报, 2005, 24(5): 386-389.Jia Y F, Lai G J, and Liu P K. Simulation and design of a Kaband fundamental wave gyro-twt amplifier. J. Infrared MillimWaves, 2005, 24(5): 386-389.[9]来国军，贾云峰，刘濮鲲. W 波段回旋行波管放大器绝对不稳定性的研究. 强激光与离子束, 2005, 17(12): 1865-1869.Lai G J, Jia Y F, and Liu P K. Absolute instability ingyro-traveling-wave tube. High Power Laser and ParticleBeams, 2005, 17(12): 1865-1869.[10]Baird J M and Lawson W. Magnetron injection gun (MIG)design for gyrotron application[J].Int .J. Electron.1986, 61(6):953-967[11]Caplan M and Thorington C. Improved computer modelingof magnetron injection gun for gyrotrons[J].Int.J.Electron.1981, 51(1):415-426[12]Nguyen K T and Danly B G. Electron gun and collectordesign for 94-GHz gyro-amplifiers[J].IEEE Trans. on PlasmaScience.1998, 26(3):799-813[13]Choi J J. Design of a temperature limited single-anodemagnetron-injection-gun[J].Int.J. Infrared and MillimeterWaves.1999, 20(2):239-252[14]Liu P K, Borie E, and Kartikeyan M V. Design of a 24GHz,25-50kW technology gyrotron operating at the second harmonic[J].Int. J. Infrared and Millimeter Waves.2000, 21(12):1917-1943[15]Wang Ch, Yeh Y S, and Yang T T, et al.. A mechanicallytunable magnetron injection gun[J].Rev Sci. Instrum.1997,68(8):3031-3035
