一种基于射线跟踪的射线管分裂新方法
doi: 10.3724/SP.J.1146.2006.01454
A Novel Splitting Technique of Ray Tubes Based on Ray Tracing
-
摘要: 该文提出了一种基于射线跟踪方法的射线管分裂新技术确定性射线管分裂法，同时给出该方法的解析分裂格式和完备性说明。仿真计算证明，在相同预测精度条件下，与两种已知的射线管方法相比，该方法具有花费CPU时间较少、计算效率较高的优点。用该方法在室内环境中进行接收功率预测，仿真结果与公开发表的文献结果相比，一致性良好。Abstract: In this paper, a novel splitting technique of ray tubes based on ray tracing method is put forward, which is called the deterministic splitting method of ray tubes. At the same time, the analytic splitting format and the demonstration of self-contained characteristic is provided. The simulation results prove that the proposed method possesses the merits of less CPU time and higher computing efficiency, compared with two known methods of ray tubes on the condition of same prediction precision. The prediction of received power has been done with this method in indoor environment. A good agreement is achieved between the simulated results and the published results.
-
Hamid M A K and Johnson W A. Ray-optical solution for thedyadic Greens function in a rectangular avity[J].Electron. Lett.1970, 6(10):317-319[2]Honcharenko W, et al.. Mechanisms governing UHF propagationon single floors in modern office buildings[J].IEEE Trans. onVehic. Technol.1992, 41(4):496-504[3]Chen Shin hon and Jeng Shyh kang. An SBR/ Imageapproach for radio wave propagation in indoor environmentswith metallic furniture. IEEE Trans. on AP, 1997, 45(1):98-106.[4]Tan S Y and Tan H S. A microcellular communicationspropagation model based on the uniform theory of diffractionand multiple image theory[J].IEEE Trans. on Antenn. Propaga.1996, 44(2):1317-1325[5]Hae Won Son and Noh Hoon M yung. A deterministic raytube method for microcellular wave propagation predictionModel[J].IEEE Trans. on Antennas and Propagat.1999, 47(8):1344-1350[6]Kpeuzgruder P, Unterberger P, and Gahleinter R. A raysplitting model for indoor radio propagation associated withcomplex geometries. IEEE VTC, Australia, 1993: 227-230.[7]Kreuzgruber P, Brundl T, Kuran W, and Gahleitner R.Prediction of indoor radio propagation with the ray splittingmodel including edge diffraction and rough surfaces.Proceedings of the 1994 IEEE 44th Vehicular Technologyconference, IEEE, Australia, 1994: 878-882.[8]Hhammoudeh A K. Millimetric wavelengths radiowavepropagation for line-of-sight indoor microcellular mobilecommunications[J].IEEE Trans. on Vehic. Technol.1995, 44(3):449-460[9]陈泓, 室内声强分布的高效预测分析方法[D]. 南京邮电大学,2006. -
