新型宽带U型缝贴片天线阵
doi: 10.3724/SP.J.1146.2006.01351
Ultra Wideband Antenna Design Using U-slot
-
摘要: 该文介绍了一种性能优良的四元U型缝贴片天线阵。该阵面由一新型的宽带匹配网络馈电，能量通过地板上的馈电缝耦合到上面的U型缝贴片上。这种类型的天线阵可以在10.4-16.7GHz的频率内工作，阻抗带宽达46.5%，最大增益为15dBi，增益在13dBi以上的频率范围达30%，交叉极化电平在整个频带内均小于-18dB。Abstract: A new antenna array consisting of U-slot microstrip patches is introduced. The array is fed by a novel wideband matching network and the energy is coupled to the U-slot patches through the feed slot on the ground. The operating frequency range of antenna array is from 10.4 to 16.7GHz, corresponding to an impedance bandwidth of 46.5%. The gain is above 13dBi from 11-15GHz.
-
James J R, Hall P S, and Wood C. Microstrip Antenna Theory and Design. London: Peter Peregrinus LTD, 1981: 101-103.[2]Huynh T and Lee K F. Single layer single patch wideband microstrip antenna[J].Electronics Letters.1995, 31(16):1310-[3]Oh Soonsoo, Seo Seongho, and Yoon Mikyoung. A broadband microstrip antenna array for LMDS applications[J].Microwave and Optical Technology Letters.2002, 32(1):35-37[4]Garg R and Bhartia P. Microstrip Antenna Design Handbook. Artech House, 2001: 875. [5] Nishiyama E, Aikawa M, and Egashira S. Stacked microstrip antenna with wide bandwidth and high gain. IEEE Trans. on Antennas Propagat., 2004, 151(2): 143-148.[5]Deshmukh A A and Kumar Girish. Compact broadband stacked microstrip antennas. Microwave and Optical Technology Letters, 2005, 48(1): 93-96.[6]Kushwas R P S, Dubey M, and Singhal P K. Design of a triple layer microstip patch antenna. 2006 IEEE Internation Workshop on Antenna Technolog : Small Antennas and Novel Metamaterials, 2006: 49-52.[7]Clenet M and Shafai L. Widebamd signle layer mirostip antenna for arra applications[J].Electronic Letters.1999, 35(16):1292-1293[8]Yang F, Zhang X X, and Samii Y. Wide-band E-shaped patch antennas for wireless communications[J].IEEE Trans. on Antennas Propagat.2001, 49(7):1094-1100[9]Wong K L and Hsu W H. A broad-band rectangular patch antenna with a pair of wide slits[J].IEEE Trans. on Antennas Propagat.2001, 49(9):1345-1347[10]Zhang J. Theory and engineering of microstrip antennas. Beijing: National Defence Industry Press, 1988: 50-58. 期刊类型引用(11)
