MLFMA分析复杂载体平台上天线问题

阙肖峰; 聂在平; 胡俊

doi:10.3724/SP.J.1146.2006.01271

MLFMA分析复杂载体平台上天线问题

doi: 10.3724/SP.J.1146.2006.01271

基金项目:

国家自然科学基金重点项目(60461010)资助课题

计量
- 文章访问数: 2968
- HTML全文浏览量: 74
- PDF下载量: 915
- 被引次数: 0
出版历程
- 收稿日期: 2006-08-28
- 修回日期: 2007-01-26
- 刊出日期: 2008-03-19

Analysis of Antennas Mounted on Complex Platforms Using MLFMA

摘要

摘要: 该文分析了导体介质复合结构平台上线天线的辐射问题。利用等效原理建立EFIE-PMCHW表面积分方程组，定义线、面和连接基函数描述复杂结构上电流分布，分析了导体介质分界面处基函数的处理；利用多层快速多极子方法(MLFMA)加速迭代求解过程中的矩阵矢量相乘运算，并用于有耗媒质求解。MLFMA的运用极大地提高了求解实际电大问题的能力。数值计算结果验证了方法的正确性和高效性。
- 线天线; 多层快速多极子方法; 导体介质复合结构; 平台
Abstract: Wire antennas mounted on complex platform combined with conducting and dielectric objects are analyzed in this paper. EFIE-PMCHW boundary coupled integral equations are constructed by using equivalence principle. The surface, wire and junction basis functions are defined to simulate the current distribution on the complex structure and the selection of the basis functions on the boundary of the conducting/dielectric interface is analyzed. Multi-Level Fast Multipole Algorithm (MLFMA) is employed to accelerate the matrix-vector multiplication and solve the loss problem. Application of MLFMA increases the ability to solve the large-scale problem. Numerical examples validate this method and demonstrate the accuracy and high efficiency of this method.

HTML全文

参考文献(1)

Chao H Y, Song G M, Michielssen E, and Chew W C. The multilevel fast multipole algorithm for analyzing electromagnetic radiation from complex surface-wire structures. Proceedings of the 1998 Antenna Applications Symposium, Alerton Park, Monticello, IL, 1998: 291-303.[2]万继响, 张玉, 梁昌洪. 任意导体与线天线连接问题的MOM分析[J].电波科学学报.2003, 18(5):523-528Wan J X, Zhang Y, and Liang C H. Method of moment analysis of connect between wire antennas and arbitrary shape conductors. Chinese Journal of Radio Science, 2003, 18 (5): 523-528.[3]Lu C C and Chew W C. A coupled surface-volume integral equation approach for the calculation of electromagnetic scattering from composite metallic and material targets. IEEE Trans on AP, 2001, 48(12): 1866-1868.[4]姚海英. 介质以及涂敷介质结构电磁散射特性的基础研究: 积分方程方法及其快速求解. [博士论文]. 电子科技大学, 2002.[5]Yao H Y. Basic study of electromagnetic scattering from dielectric and coated structures-integral equation method and its fast solver. [Dissertation]. University of Electronic Science and Technology of China, 2002. [5] Rao S M, Wilton D R, and Glisson A W. Electromagnetic scattering by surfaces of arbitrary shape. IEEE Trans on AP, 1982, 30(5): 409-418.[6]Costa M F and Harrington R F. Minimization of radiation from computer systems. Proc. Int. Electrical Electronics Conference, Canada, Sept.1983: 660-665.[7]聂在平, 胡俊, 姚海英, 王浩刚. 用于复杂目标三维矢量散射分析的快速多极子方法. 电子学报. 1999, 27(6): 104-109.[8]Nie Z P, Hu J, Yao H Y, and Wang H G. The fast multipole methods for vector analysis of scattering from 3-dimensional objects with complex structure. Acta Electronica Sinca, 1999, 27(6): 104-109.[9]Geng N, Sullivan A, and Carin L. Fast multipole method for scattering from an arbitrary PEC target above or buried in a lossy half space. IEEE Trans on AP, 2001, 49(5): 740-748.
