利用接地板开槽减缩微带贴片天线的RCS
doi: 10.3724/SP.J.1146.2006.01016
Reducing the RCS of Microstrip Patch Antenna by Cutting Slots on the Groundplane
-
摘要: 接地板开槽可以改变微带天线的辐射特性及阻抗特性,在微带贴片天线的频带展宽中已有所应用。该文给出了微带贴片天线散射特性的矩量法求解过程,并分析了接地板开槽对天线雷达截面(RCS)的影响。与短路针加载相结合,给出了一种接地板开槽形式。结果表明,据此设计的微带贴片天线在较宽频带内实现了RCS的减缩,同时天线的辐射性能保持良好,对天线的隐身有一定的借鉴作用。Abstract: The radiation and impedance characteristic of microstrip antenna may be influenced by cutting slots on the groundplane with applications to widening the frequency band. The Method of Moment(MoM)which is used to solve the scattering of microstrip patch antenna is presented. The effect of cutting groundplane slots on the RCS is analyzed and a scheme of cutting slots is put forward combining shorted-posts load. The results indicate that the RCS is reduced a lot during a very wide frequency band, while antenna radiation performance remains. The conclusion is useful for the antenna radar cross section reduction.
-
钟顺时. 微带天线理论与应用.第一版, 西安:西安电子科技大学出版社, 1991: 1-2.[2]杨超, 阮颖铮, 冯林. 微带天线RCS减缩技术及分析方法[J].电波科学学报.1994, 9(4):52-56[3]冯林, 阮颖铮. 天线RCS减缩技术研究的新进展. 电子科技大学学报,1995, 24(7): 23-26.[4]Wilsen C B, Davidson D B, Odendaal J W, and Janse van Rensburg D J. The RCS reduction of microstrip patch antennas. Tenth International Conference on Antennas and Propagation, 14-17 April 1997, vol.1: 174-177.[5]Chiou T W and Wong K L. Designs of compact microstrip antennas with a slotted gound plane. Antennas and Propagation Society International Symposium, 2001. IEEE, 8-13 July, 2001, vol.2: 732-735.[6]Wong K L, Kuo J S, and Chiou T W. Compact microstrip antennas with slots loaded in the ground plane. Eleventh International Conference on Antennas and Propagation, 17-20 April, 2001, vol.2: 623-626.[7]贺秀莲. 微带天线的数学建模理论与数值分析方法研究. [博士论文], 西安: 西安电子科技大学, 2005.[8]张洪波, 龚书喜. 双H形槽减缩微带天线RCS[J].空间电子技术.2006, 3(1):37-39 期刊类型引用(8)
