一种多通道SAR高分辨率宽测绘带成像算法
doi: 10.3724/SP.J.1146.2006.00986
An Algorithm of Multichannel SAR High-Resolution and Wide-Swath Imaging
-
摘要: 合成孔径雷达采用多个天线可以实现高分辨率、宽测绘(HRWS)带成像，增强信噪比，改善动目标检测时的模糊抑制性能。以HRWS成像为目的，该文提出了一种将接、收阵元的双通道数据映射成单通道数据的算法。该算法在二维频域可以根据平台速度变化，进行相位校正。并且在方位向只需一次傅里叶变换，因而具有较高的运算效率。性能分析和仿真结果表明了算法的有效性。Abstract: Synthetic Aperture Radar (SAR) with multiple antennas can realize High-Resolution Wide-Swath (HRWS) imaging，improve Signal to Noise Ratio (SNR) and improve ambiguity suppression for Moving Target Indication (MTI). This paper proposes an algorithm can realize HRWS imaging based on conversion bi-static data into mono-static data. The algorithm can correct phase according to velocity fluctuation of platform change. Furthermore the algorithm has high efficiency, for azimuth data need only one time FFT operation. Performance analysis and computer simulation are presented to illustrate the validity of the algorithm.
-
Cantofio L J. Space-Based Radar Handbook. Boston, MA:Artech House, 1989: 127-132.[2]Griffiths H D and Mancini P. Ambiguity suppression in SARSusing adaptive array techniques in proc. IGARSS, London,UK., 1991: 1010-1018.[3]Callaghan G D. and Longstaff I D. Wide-swath space-borneSAR and range ambiguity. Proceedings of Radar 97, October1997: 248-252.[4]Currie A and Brown M A. Wide-swath SAR. Proc. Inst. Elect.Eng. F., 1992, 139(2): 122-135.[5]Stiles J M and Goodman N A. Processing of multi-apertureSAR to produce fine-resolution images of arbitrarily largeextent. Radar Conference, 2001. Proceedings of the 2001,IEEE, 2001: 451-456.[6]Li Zhengfang, Wang Hongyang, Su Tao, and Bao Zheng.Generation of wide-swath and high-resolution SAR imagesfrom multichannel small spaceborne SAR systems[J].IEEEGeoscience and Remote Sensing Letters.2005, 2(1):82-86[7]Younis M and Wiesbeck W. Digital beamforming in SARsystems[J].IEEE Trans. on Geosicence and Remote Sensing.2003, 41(7):1735-1739[8]Soumekh M. Bistatic synthetic aperture radar inversion withapplication in dynamic object imaging[J].IEEE Trans. onSignal Processing.1991, 39(9):2044-2055[9]Franceschett G, Mazzeo A, and Mazzocca N. An efficientSAR parallel processor. IEEE Trans. on Aerospace andElectronic System, 1991, 27(2): 356-366.[10]Brenner N M. Fast Fourier transform of externally storeddata. IEEE Trans. on Audio and Electroacoustics, 2003, 41(7):128-132. -
