一种新型SRR缺陷地面结构低通滤波器

吴边; 李斌; 梁昌洪

doi:10.3724/SP.J.1146.2006.00756

一种新型SRR缺陷地面结构低通滤波器

doi: 10.3724/SP.J.1146.2006.00756

基金项目:

国家自然科学基金(60501023)和国家973重大项目基金(00300113)资助课题

计量
- 文章访问数: 3672
- HTML全文浏览量: 114
- PDF下载量: 1774
- 被引次数: 0
出版历程
- 收稿日期: 2006-05-31
- 修回日期: 2006-10-16
- 刊出日期: 2007-12-19

A Novel SRR Defected Ground Structure for Lowpass Filter

摘要

摘要: 该文提出一种新型开口谐振环(Split-Ring Resonator, SRR)缺陷地面结构(Defected Ground Structure, DGS)。这种结构与传统哑铃形DGS结构相比，具有陡峭的带隙和平坦的低通特性。文中详细分析了开口谐振环DGS单元的等效电路以及结构参数与电参数之间的关系。在此基础上提出一种加载开路枝节的SRR DGS单元模型以提高带外抑制，采用这种单元的级联周期结构设计并制作了一种紧凑的S波段低通滤波器。测试结果表明，该滤波器带内插损小于0.5dB，带外抑制度在30 dB以上。
- 低通滤波器;开口谐振环;缺陷地面结构
Abstract: A novel Split-Ring Resonator (SRR) Defected Ground Structure (DGS) is presented. Compared with the conventional dumbbell DGS, this structure has a sharp band-gap and flat low-pass characteristic. A detailed analysis of the equivalent circuit of the cell model and the relationship between physical sizes and electrical parameters is made. Then an improved SRR DGS cell model loaded with open stubs is proposed in order to improve the out-band suppression. Based on this structure, a compact S-band microstrip lowpass filter is designed and fabricated. The measured results show that, this filter has a low insertion loss of below 0.5dB and a high out-band suppression of more than 30dB.

HTML全文

参考文献(1)

Yablonovitch E, Gmitter T J, and Leung K M. Photonic band structure: The face centered cubic case employing nonspherical atoms[J].Phys. Rev. Lett.1991, 67(1):2295-2298[2]Park J I, Kim C S, and Kim J, et al.. Modeling of a photonic bandgap and its application for the low-pass filter design [C]. Asia Pacific Microwave Conference,Singapore, 1999: 331-334.[3]Kim C S, Park J I, and Dal A, et al.. A novel 1-D periodic defected ground structure for planar circuits [J].IEEE Microwave Guided Wave Lett.2000, 10(4):131-133[4]Pendry J B, Holden A J , and Robbins D J, et al. Magnetism from conductors and enhanced nonlinear phenomena[J].IEEE Trans. on Microwave Theory Tech.1999, 47(11):2075-2084[5]Gay-Balmaz P, Maccio C, and Martin O J F. Microwire arrays with plasmonic response at microwave frequencies[J].Applied Physics Letters.2002, 81(15):2896-2898[6]Markos P and Soukoulis C M. Numerical studies of left-handed materials and arrays of split ring resonators. Phys Rev E, 2002, 65(036622): 1-8.[7]Liu Hai-Wen, Li Zheng-Fan, Sun Xiao-Wei, and Mao Jun-Fa. An improved 1-D periodic defected ground structure for microstrip line[J].IEEE Microwave Wireless Comp.2004, 14(4):180-182[8]Park J S, Kim J, Lee J, and Myung S. A novel equivalent circuit and modeling method for defected ground structure and its application to optimization of a DGS lowpass filter. IEEE Microwave Theory Tech. Symp. Dig., Seattle WA ,2002: 417-420.
