采用BICM-ID的PP-OFDM系统及后缀幅度优化
doi: 10.3724/SP.J.1146.2006.00150
PP-OFDM with BICM-ID and Postfix Amplitude Optimization
-
摘要: 该文设计了一种用于正交频分复用(OFDM)系统的新型保护间隔信号-导频后缀(Pilot Postfix, PP),并构建了采用比特交织编码调制-迭代解码(BICM-ID)技术的PP-OFDM系统。PP由OFDM符号中的频域导频符号进行逆傅氏变换(IFFT)生成,在接收端可与OFDM符号中的导频相干合并,从而提高信道估计性能。该文给出了相应的信道估计、均衡和BICM-ID算法,并通过研究信道估值误差带来的接收信号有效信噪比变化,给出了PP幅度优化设计方法。仿真表明:选取适当的PP大小后,PP-OFDM比循环前缀/补零后缀-OFDM(CP/ZP-OFDM)的信道估计性能更好,误包率更低。
-
关键词:
- 无线通信 /
- 正交频分复用 /
- 比特交织编码调制-迭代解码
Abstract: A new postfixing scheme for OFDM is proposed, where PP (Pilot Postfix) is inserted in the guard interval after OFDM symbol, and PP-OFDM system is constructed with BICM-ID(Bit-Interleaved Coded Modulation with Iterative Decoding). PP is generated by IFFT to frequency domain pilot symbols in OFDM symbol, and can be combined with those pilots in OFDM symbol at receiver. Channel estimation,equalization and BICM-ID algorithm for PP-OFDM are also proposed. Effective SNR degradation caused by imperfect channel estimation is studied, and a method is proposed to optimize the amplitude of PP. With the optimal PP amplitude, simulations show that PP-OFDM has better channel estimation performance and lower PER (Packet Error Rate) than CP/ZP-OFDM (Cyclic Prefix/Zero Postfix -OFDM). -
[1] [1] ETSI. Broadband Radio Access Networks (BRAN); HIPERLAN type 2 technical specification; Physical (PHY) layer [S]. Technical Specification ETSI TS 101475, 2001. [2] Muquet B and Zhengdao W, et al.. Cyclic prefixing or zero padding for wireless multicarrier transmissions [J].IEEE Trans. on Commun.2002, 50(12):2136-2148 [3] Pfletschinger S and Sanzi F. Iterative demapping for OFDM with zero-padding or cyclic prefix [C]. IEEE International Conference on Communications, Paris France, Jun. 2004: 842-846. [4] Caire G, Taricco G, and Biglieri E. Bit-interleaved coded modulation [J].IEEE Trans. on Information Theory.1998, 44(3):927-946 [5] 焦现军, 陈江, 蒋伟, 项海格. 增强导频的新型OFDM同步信号[C]. 第十三届中国电子学会信息论学术年会, 长沙:国防科技大学, 2005年10月: 227-231. [6] 焦现军, 陈江, 蒋伟, 项海格. 一种新的OFDM后缀信号PP[J]. 电子学报, 2006, 34(7): 1216-1221. [7] Hsieh Meng-Han and Wei Che-Ho. Channel estimation for OFDM systems based on comb-type pilot arrangement in frequency selective fading channels [J].IEEE Trans. on Consumer Electronics.1998, 44(1):217-225 [8] Sanzi F, Sven J, and Speidel J. A comparative study of iterative channel estimators for mobile OFDM systems [J].IEEE Trans. on Wireless Communications.2003, 2(5):849-859 [9] ETSI Normalization Committee. Channel models for HIPERLAN/2 in different indoor scenarios [C]. Norme ETSI, Sophia-Antipolis. France, 1998, document 3ERI085B. -
