行波管多级降压收集极CAD软件研究与实现

黄桃; 杨中海; 李斌; 胡权; 廖莉; 肖礼; 朱小芳

doi:10.3724/SP.J.1146.2006.00112

行波管多级降压收集极CAD软件研究与实现

doi: 10.3724/SP.J.1146.2006.00112

基金项目:

国家部级基金资助课题

计量
- 文章访问数: 3343
- HTML全文浏览量: 89
- PDF下载量: 769
- 被引次数: 0
出版历程
- 收稿日期: 2006-01-23
- 修回日期: 2006-09-26
- 刊出日期: 2007-08-19

Study and Realization of Multistage Depressed Collector CAD Software for Traveling Wave Tubes

摘要

摘要: 该文讨论了行波管多级降压收集极CAD理论模型，在二维轴对称条件下，对网格自动划分技术、二次电子发射模型、空间电荷效应计算方法、外加磁场影响、收集极效率计算方法等进行了深入研究，并在现有模型基础上进行了修改，以获得更好的模拟效果。同时在此基础上，开发了行波管多级降压收集极CAD软件UESTC_MDC，并对该软件的使用进行了简单的介绍。最后根据国外研究发展动向，对我国行波管多级降压收集极CAD软件的发展提出了一些可参考的意见和建议。
- 行波管;多级降压收集极;CAD;二次电子
Abstract: In this paper, the theoretical model of multistage depressed collector for traveling wave tubes, including the technology of automatic mesh generation, the effects of secondary electrons, space charges, magnetic fields and the method of computation of collectors efficiency, is presented in detail. Based on this theory, a two-dimensional software is developed and is used in the design of symmetrical multistage depressed collectors. Finally, the recent development of the theory is summarized and some referable advices are suggested.

HTML全文

参考文献(1)

电子管设计手册编委会. 行波管电子光学系统设计手册. 北京:国防工业出版社, 1981.[2]廖平. 行波管电子光学系统CAD研究. [博士论文], 成都：电子科技大学, 2004.[3]高讯鸿. 多级降压收集极CAD研究. [硕士论文], 成都：电子科技大学, 2004.[4]寇建勇, 马少云, 孙瑜等. 多级降压收集极的模拟仿真软件. 真空电子技术, 2003, 5: 87-90. Kou Jian-yong , Ma Shao-yun, and Sun Yu. Simulation software for multistage depressed collector. Vacuum Electronics, 2003, 5: 87-90.[5]黄桃, 杨中海, 胡权等. TWTCAD多级降压收集极CAD设计与实现. 中国电子学会真空电子学分会第15届学术年会, 昆明, 2005: 320-323.[6]Ramins P, Kosmahl H G, and Force D A, et al.. Verification of computer-aided designs of traveling-wave tubes utilizing novel dynamic refocuses and graphite electrodes for the multistage depressed collector. NASA tp-2524, 1985: 155-158.[7]Petillo J, Eppley K, and Panagos D, et al.. The MICHELLE three-dimensional electron gun and collector modeling tool: theory and design[J].IEEE Trans. on Plasma Science.2002, 30(3):1238-1264[8]Coco S, Emma F, and Laudani A, et al.. COCA: A novel 3-D FE simulator for the design of TWTs multistage collectors[J].IEEE Trans. on Electron Device.2001, 48(1):24-31[9]廖莉, 杨中海, 李斌等. TWTCAD系统框架设计与软件验证. 中国电子学会真空电子学分会第15届学术年会, 昆明, 2005: 12-15.[10]Yang Zhonghai, Li Bin, and Liao Li, et al.. Application and Validation of the TWTCAD Integrated Framework. ICMMT, Beijing, 2004: 723-726.[11]Li Bin and Yang Zhonghai. Three-dimensional nonlinear theory of traveling wave tubes and simulation[J].Chinese Physics.2003, 12(11):1235-1240[12]Herrmannsfeldt W B. Electron Trajectory Program. America: Stanford, SLAC, 1979.[13]Vaughan J R M. Secondary emission formulas. IEEE Trans on Electron Devices, 1993, 40(4): 830.[14]Vaughan J R M. A new formula for secondary emission yield[J].IEEE Trans on Electron Devices.1989, 36(9):1963-1967
