一种基于双正交模的新型天线阵方向图综合方法
doi: 10.3724/SP.J.1146.2006.00042
A Biorthogonal-Mode Based Approach to Pattern Synthesis for Array Antennas
-
摘要: 本文提出一种新型综合阵列天线方向图的模式方法。该方法基于双正交模式理论，考虑了阵元之间的耦合作用的影响，可以对任意形状的阵列天线进行方向图综合。利用双正交模式综合方法可以快速有效地获得每个阵元的特定激励，以期阵列天线的方向图满足特定的需求。模式组之间的双正交特性保证了该方法所得天线阵列方向图与期望方向图之间良好的一致性。通过对所需电场的加权，可以将整个球面上的二维曲面积分运算转化为一维线积分运算，使得方向图综合过程的计算量大为减少。若干阵列天线方向图综合实例验证了该方法的正确性和有效性。
-
关键词:
- 天线阵列;方向图综合;双正交模;加权场
Abstract: A novel approach to arbitrary array pattern synthesis based on biorthogonal modes is presented in this paper. The algorithm involving arrays with arbitrary geometry and incorporating mutual coupling effect, can accurately determine element excitations required to yield desired patterns. The mutual orthogonality of modes is used to ensure the agreement between the desired and computed patterns. When the weighted field is applied, the double integral can be simplified by performing one variable integral, so synthesis procedure is less time-consuming. The effectiveness of the approach is demonstrated with several numerical examples. -
Dolph C L. A current distribution for broadside arrays which optimizes the relationship between beam width and side-lobe level[J].Proc. IRE.1946, 34(6):335-348[2]Woodward P M and Lawson J D. The theoretical precision with which an arbitrary radiation pattern may be obtained from a source of finite size. J. IEE, 1948, 95(9): 363-370.[3]Taylor T T. Design of line-source antenna for narrow beamwidth and low sidelobes. IRE Trans.on Antennas Prograt., 1955, 3(1): 16-28.[4]Kang Y W and Pozar D M. Correction of error in reduced sidelobe synthesis due to mutual coupling[J].IEEE Trans. on Antennas Prograt.1985, 33(9):1025-1028[5]Georgiadis A. On antenna array design using orthogonal modes[J].IEEE Trans on Antennas Prograt.2004, 52(7):1905-1909[6]Siakavara K and Sahalos J N. A simplification of the synthesis of parallel wire antenna arrays[J].IEEE Trans. on Antennas Prograt.1989, 37(7):936-940[7]Unz H. Nonuniformly spaced arrays: The orthogonal method[J].Proc. IEEE.1966, 54(1):53-54[8]曹伟，严鑫海，朱效军. 双正交本征函数方法及其应用. 电子学报, 1989, 17(5): 124-127.[9]Cao Wei, Yan Xinhai, and Zhu Xiaojun. Biorthogonal mode approach to radiation and scattering problems. Proc. International Symposium on Antennas and EM Theory, Shanghai, China, Aug. 1989.[10]曹伟，陈劲松. 内谐振条件下导体散射特性的双正交模法分析. 电波科学学报，1994, 10(1): 16-22.[11]Harrington R F. Field Computation by Moment Methods. New York: Macmillan, 1968.[12]Harrington R F and Mautz J R. Theory of characteristic modes for conducting bodies[J].IEEE Trans on Antennas Prograt.1971, 19(5):622-628[13]Inagaki N and Garbacz R. Eigenfunctions of composite Hermitian operators with application to discrete and continuous radiating systems[J].IEEE Trans on Antennas Prograt.1982, 30(4):571-575[14]Pozar D M. Antenna synthesis and optimization using weighted Inagaki modes[J].IEEE Trans on Antennas Prograt.1984, 32(2):159-165[15]Harrington R F and Mautz J R. Pattern synthesis for loaded n-port scatterers[J].IEEE Trans on Antennas Prograt.1974, 22(2):184-190 -
