CLEAN算法在机载毫米波综合孔径成像中的应用

何云涛; 江月松; 钟宇

doi:10.3724/SP.J.1146.2005.01615

CLEAN算法在机载毫米波综合孔径成像中的应用

doi: 10.3724/SP.J.1146.2005.01615

基金项目:

航空基础科学基金(05F51073)和航天科技创新基金共同资助课题

计量
- 文章访问数: 3848
- HTML全文浏览量: 124
- PDF下载量: 1530
- 被引次数: 0
出版历程
- 收稿日期: 2005-12-13
- 修回日期: 2006-08-16
- 刊出日期: 2007-07-19

An Application of the CLEAN Algorithm in Airborne mm-wave Synthetic Aperture Imaging

摘要

摘要: 该文将非即时u-v覆盖的综合孔径射电天文观测中的CLEAN算法应用到即时u-v覆盖的机载二维被动毫米波综合孔径成像中，避免因空间频率覆盖的不完整而产生对图像质量的影响，以达到消除高旁瓣对图像产生的负面影响。该文主要分析了CLEAN算法中具体处理时的清洁脉冲类型、脉冲半峰值宽度和迭代比例因子对处理后的图像的影响。研究结果表明：当清洁脉冲半宽度峰值等于系统脉冲响应图的半峰值宽度时、迭代比例因子为1/256时以及清洁脉冲类型为高斯脉冲时有利于改善图像的质量，该结论对实际的机载被动毫米波综合孔径成像的工程研究具有重要的参考价值。
- CLEAN算法;综合孔径;毫米波成像;消卷积
Abstract: The CLEAN algorithm is introduced from non-instant u-v coverage aperture synthesis in radio astronomy to instant situation in 2-D airborne mm-wave imaging, to remove the bad influences of the undersampled u-v plane coverage to image quality so as to eliminate the negative impacts on the image caused by high side slobs. In this paper, the effects of the kind of clean impulse, the relevant FWHM and the scale coefficient to the quality of the modified image is mainly studied, and a conclusion is that: a Gauss clean impulse, a relevant FWHM equal to the FWHM of system response and the scale coefficient about 1/256 is favorable to improve the modified image. This conclusion is valuable to the real airborne mm-wave aperture synthesis imaging project.

HTML全文

参考文献(1)

Peichl M, Greiner M, and Suess H. DLR activities on aperture synthesis radiometry. IEEE IGARSS, Hawaii, US, July 2000, 7: 2981-2983.[2]Harvey A R and Appleby R. Prospects for mm-wave aperture synthesis from space-borne and aerial platforms. Proc. SPIE, 2000, 4091: 27-38.[3]Tsao J and Steinberg B D. Reduction of sidelobe and speckle artifacts in microwave imaging: The CLEAN technique[J].IEEE Trans. on Antennas and Propagation.1988, 36(4):543-556[4]Hogbom J A. Aperture synthesis with a non-regular distribution of interferometer baselines. Astron. Astrophys, 1974, 15 (2): 417-426.[5]Schwarz U J. Mathematical - statistical description of the iterative beam removing technique (method CLEAN). Astron. Astrophys, 1978, 65(2): 345-356.[6]Chick K M and Warman K. Using the CLEAN algorithm to restore undersampled synthetic aperture sonar images. MTS/IEEE Conference and Exhibition, 2001, 1(5-8): 170-178.[7]Hai D. Effective CLEAN algorithms for performance-enhanced detection of binary coding radar signals[J].IEEE Trans. on Signal Processing.2004, 52(1):72-78[8]Alam M and McClellan J H. Near field imaging of subsurface targets using wide-band multi-static RELAX/CLEAN algorithm. IEEE ICASSP, Philadelphia, US, 2005, IV: 1097-1100.[9]Ruf C S, Swift C T, and Tanner A B, et al.. Interferometric synthetic aperture microwave radiometry for the remote sensing of the earth. IEEE Trans. on GRS, 1988, 26(5): 597-611.[10]Peichl M, Suess H, and Suess M. Microwave imaging of the brightness temperature distribution of extended areas in the near and far field using two-dimensional aperture synthesis with high spatial resolution[J].Radio Science.1998, 33(3):781-801[11]陈海亭，江月松，钟宇. 二维圆周光综合孔径阵的优化排列及其成像特性研究. 光学学报，2005, 25(12): 1616-1623.Chen Hai-ting, Jiang Yue-song, and Zhong Yu. Study of optimization and imaging characteristics of two-dimensional circle array for optical synthetic aperture system. Acta Optica Sinica, 2005, 25(12): 1616-1623.[12]Cornwell T J. A novel principle for optimization of the instantaneous Fourier plane coverage of correlation arrays[J].IEEE Trans. on Antennas and Propagation.1988, 36(8):1165-1167
