均匀直线阵幅相误差校正的扰动分析及最优化算法
doi: 10.3724/SP.J.1146.2005.01611
Perturbation Analysis of Gain and Phase Error Calibration for Uniform Linear Array with Optimal Algorithms
-
摘要: 该文研究均匀直线阵幅度和相位误差校正问题。首先分析了估计协方差矩阵各对角线元素扰动量的统计特性，同时给出了不同对角线上幅度和相位扰动量的统计方差的显式表达式。分析结果表明，相同对角线上，不同元素的幅度和相位具有相同分布，而不同对角线上，幅度和相位扰动量的方差不同。基于此结果，分析了一类基于Toeplitz结构幅度和相位误差的校正方法，说明基于主对角线的幅度误差校正方法和基于第一上对角线的相位误差校正方法分别是幅度和相位误差的最优校正方法。计算机结果验证了本文分析的正确性。
-
关键词:
- 阵列信号处理;方向估 计;误差校正
Abstract: The gain and phase error calibration for Linear Equi-spaced Arrays (LEA) is considered in this paper. The analysis of the covariance matrix perturbation along different diagonal lines due to finite snapshot is first considered, and an apparent formula for the variance of the gain and phase perturbations along different diagonal lines is derived. This result reveals that the statistics analyses of the perturbation along different diagonal lines are different. Based on this analytic result, it is found out that the optimal gain and phase error calibration methods are respectively based on main diagonal line and the first upper diagonal line. Computer simulation results verified the analyses. -
Schmidt R O. Multiple emitter location and signal parameters estimation[J].IEEE Trans. on Antennas Propagation.1986, 34(3):267-280[2]Roy R and Kailath T. ESPRIT-estimation of signal parameters via rotational invariance technique. IEEE Trans. on Acoust. Speech, Signal Process., 1989, ASSP-37(7): 984-995.[3]Stoica P and Nehorai A. Music, maximum likelihood and Cramer-Rao bound[J].IEEE Trans. on Acoust. Speech, Signal Process.1989, 37(5):720-741[4]Paulraj A and Kailath T. Direction of arrival estimation by eigenstructure methods with unknown sensor gain and phase. Proc. Int. Conf. Acoust., Speech, Signal Processing( ICASSP), Tampa, FL, March 1985: 640-643.[5]韩芳明，张守宏，潘复平. 阵列误差对MUSIC算法性能的影响与校正. 西安电子科技大学学报，2003, 30(5): 585-589. Han Fang-ming, Zhang Shou-hong, and Pan Fu-ping. Effect of array uncertainty on the performance of MUSIC and its calibration. Journal of Xidian University(Natural Science), 2003, 30(5): 585-589.[6]Weiss A J and Friedlander B. Eigenstructure methods for direction finding with sensor gain and phase uncertainties. Circuits Sys. Signal Process., 1990, 9(2): 272-300.[7]Wylie M P, Roy S and Messer H. Joint DOA estimation and phase calibration of linear equispaced (LES) arrays[J].IEEE Trans. on Signal Processing.1994, 42(12):3449-3459 -
