一种直升机的舰船Dechirp实测数据SAR成像方法

李亚超; 周峰; 邢孟道; 保铮

doi:10.3724/SP.J.1146.2005.01535

一种直升机的舰船Dechirp实测数据SAR成像方法

doi: 10.3724/SP.J.1146.2005.01535

基金项目:

国家自然科学基金(60502044)和微波成像重点实验室基金(5144202 0404DZ0102)资助课题

计量
- 文章访问数: 3508
- HTML全文浏览量: 91
- PDF下载量: 875
- 被引次数: 0
出版历程
- 收稿日期: 2005-11-28
- 修回日期: 2006-05-22
- 刊出日期: 2007-08-19

An Effective Method for Ship Dechirp Data Imaging in Helicopter SAR System

摘要

摘要: 直升机由于飞行不稳将会给运动目标成像带来很大的误差，尤其是对复杂运动舰船的成像。该文提出了一种基于利用运动补偿并两次利用广义二阶keystone变换同时结合利用孤立的散射点进行WVD变换估计多普勒参数的方法来分别消除距离弯曲和距离走动并最终对舰船成像。文中对算法做了详细的推导证明，并最终得到了良好的成像结果。最后用3个运动点目标的仿真数据和dechirp实测舰船数据来证明该方法有效。
- Dechirp;广义keystone变换;WVD;孤立的散射点
Abstract: In view of unsteadily flying, the helicopter brings about great errors to moving targets imaging, especially SAR imaging of moving ship. So this paper shows an effective method based on an idea that uses motion compensation, general second-step keystone transform twice and at the same time, finds an isolated point and adopts WVD transform to estimate Doppler parameters for removing range walk and curvature. And what is more, the detailed deductions are given in this paper.Finally, the SAR image of moving ship is acquired in the azimuth frequency field. The simulation results of three moving point-targets and the imaging result of real ship data confirme this method.

HTML全文

参考文献(1)

Sparr T. Moving target motion estimation and focusing in SAR images[C]. International Radar Conference, Yantai, China, IEEE, 9-12 May, 2005: 290-294.Qu Chang-wen, He You, Su Feng, and Huang Yong. SAR moving targets detection based on the chirp-Fourier transform[C]. International Radar Conference, Yantai, China, IEEE, 9-12 May, 2005: 802-805.[2]陈仁元, 张长耀, 邓海涛, 王燕宇. 直升机合成孔径雷达对海面动目标成像[C]. 中国合成孔径雷达会议论文集, 合肥, 2003, 12, 1-4: 264-267.[3]李士国, 单荣光, 储晓彬, 倪晋麟. 基于SAR/ISAR的机载雷达舰船成像[J]. 信号处理, 2000, 16(2): 151-155.[4]Tang Li-bo.[J].Li Dao-jing, Hong Wen, and Cao Fang. High resolution SAR imaging of moving ships[C].Geoscience and Remote Sensing Symposium,IGARSS05 Proceedings, IEEE International, Beijing, P.R.China, 25-29 July.2005,:-[5]李杰, 向敬成, 黄顺吉. 合成孔径雷达慢运动目标成像处理的研究[J]. 电子科技大学学报, 1995, 24(2): 119-125.[6]Shun-Sheng Zhang, Tao Zeng, Teg Long, and Hai-Peng Yuan. Dim target detection based on keystone transform[J]. International Radar Conference, Yantai, China, IEEE, 9-12 May, 2005: 889-894.[7]Perry R P. SAR imaging of moving targets[J].IEEE Trans. on Aerospace and Electronic Systems.1999, 35(1):188-200[8]盛蔚, 毛士艺. 基于keystone变换的地面运动目标检测研究[J]. 系统工程与电子技术, 2002, 24(11): 2-5. Sheng Wei and Mao Shi-yi. Ground moving target detection with an SAR system based on keystone transform. Systems Engineering and Electronics, 2002, 24(11): 2-5.[9]保铮, 邢孟道, 王彤编著.雷达成像技术[M]. 北京：电子工业出版社，2005, 第2,5,6章.[10]张贤达, 保铮编著. 非平稳信号的分析与处理[M]. 北京：国防工业出版社，1998, 第2,3章.[11]L Cohen. Time-frequency distributions-review[J].Proc. IEEE, 1978, 77(1): 86-91.[12]盛蔚, 毛士艺. 一种合成孔径雷达对地面运动目标成像和精确定位的算法[J]. 电子与信息学报. 2004, 26(4): 598-606. Sheng Wei and Mao Shi-yi. An effective method for ground moving target imaging and location in SAR system. Journal of Electronics Information Technology. 2004, 26(4): 598-606.[13]邢孟道, 保铮, 郑义明, 冯大政. 适合于大型平稳和机动目标的成像算法[J]. 信号处理, 2001, 27(3): 43-45, 49.[14]陈文驰, 邢孟道. 基于keystone变换的多目标ISAR成像算法[J]. 现代雷达. 2005, 17(1): 47-55.
