一种三段式互作用结构谐波倍增回旋行波放大器互作用电路的模拟

焦重庆; 罗积润

doi:10.3724/SP.J.1146.2005.01482

一种三段式互作用结构谐波倍增回旋行波放大器互作用电路的模拟

doi: 10.3724/SP.J.1146.2005.01482

焦重庆^{①②;罗积润},
罗积润

计量
- 文章访问数: 3162
- HTML全文浏览量: 80
- PDF下载量: 889
- 被引次数: 0
出版历程
- 收稿日期: 2005-11-17
- 修回日期: 2006-05-08
- 刊出日期: 2007-08-19

Simulations of a Harmonic Multiplying Gyro-TWT with Three-Stage Interaction Circuit

Jiao Chong-qing^{①②;罗积润},
Luo Ji-run

摘要

摘要: 该文给出了一种三段式互作用结构谐波倍增回旋行波管放大器互作用电路的理论设计过程。利用线性理论研究竞争模式的起振条件，选取保证工作模式稳定的工作参数。利用自洽非线性理论研究其饱和输出性能。计算表明，在100kV，25A，速度比1.0以及速度零散5%的电子注推动下，在34.6GHz频率可获得饱和输出功率540kW，效率21.6%，增益58dB和约4.5%的3dB带宽。
- 回旋行波管;谐波倍增;Ka波段;注波互作用
Abstract: In this paper, the design procedure of a harmonic multiplying Gyro-TWT with three stage interaction circuits is presented. The starting oscillation condition of competing modes is studied with linear theory to select the working parameters for keeping the stability of working mode. The saturated output performance of the working mode is discussed by using a consistent non-linear theory. Based on large signal numerical analysis, a saturated peak power of 540kW with an efficiency of 21.6%, a gain of 58dB, and a 3dB bandwidth of 4.5% is predicted for the gyro-TWT driven by 100kV, 25A electron beam with a velocity ratio of 1.0 and velocity spread 5% at 34.6GHz.

HTML全文

参考文献(1)

Felch K L, Danly B G, and Jory H R, et al.. Characteristics and applications of fast-wave gyro-devices[J].Proc. of the IEEE.1999, 87(5):752-781[2]Chu K R, Guo H, and Granatstein V L. Theory of the harmonic multiplying gyrotron traveling wave amplifier[J].Phys. Rev. Lett.1997, 78(24):4661-4664[3]Nusinovich G S, Chen W, and Granatstein V L. Analytic theory of frequency-multiplying gyro- traveling- wave- tubes[J].Phys. Plasmas.2001, 8(2):631-637[4]Choi J J, Ganguly A K, and Armstrong C M. Frequency multiplied harmonic gyrotron-traveling- wave-tube amplifier[J].Phys. Plasmas.1994, 1(6):2058-2062[5]Lin A T and Lin C C. Amplification mechanism in the output section of the harmonic multiplying gyrotron traveling wave amplifier[J].IEEE Trans. on Plasma Sci.2002, 30(3):931-937[6]Nusinovich G S, Sinitsyn O V, and Rodgers T, et al.. Comparision of multistage gyroamplifiers operating in the frequency-multiplication regime with gyroamplifiers operating at a given cyclotron harmonic[J].IEEE Trans. on Plasma Sci.2004, 32(3):957-969[7]Baik Chan-Wook, Jeon Seok-Gy, and Kim Dae-Ho, et al.. Third harmonic frequency multiplication of a two-stage tapered gyrotron TWT amplifier[J].IEEE Trans. on Electron Devices.2005, 52(1):1-10[8]Wang Q S, Kou C S, and McDermott D B, et al.. High-power harmonic gyro-TWATspart II: nonlinear theory and design[J].IEEE Trans. on Plasma Sci.1992, 20(3):163-169[9]Chu K R and Lin A T. Gain and bandwidth of the gyro-TWT and CARM amplifiers[J].IEEE Trans. on Plasma Sci.1988, 16(2):90-104[10]Kou C S. Starting oscillation conditions for gyrotron backward wave oscillators[J].Phys. Plasmas.1994, 1(9):3093-[11]Chu K R, Chen H Y, and Hung C L, et al.. Theory and experimental of ultrahigh-gain gyrotron traveling wave amplifier[J].IEEE Trans. on Plasma Sci.1999, 27(4):391-404[12]Wang Q S, Huey H E, and McDermott D B, et al.. Design of a W-band second harmonic TE02 gyro-TWT amplifier[J].IEEE Trans. on Plasma Sci.2000, 28(6):2232-2237[13]Wang Q S, Kou C S, and McDermott D B, et al.. High-power harmonic gyro-TWATspart I: linear theory and oscillation study[J].IEEE Trans. on Plasma Sci.1992, 20(3):155-162[14]Chu K R. Theory of electron cyclotron maser interaction in a cavity at the harmonic frequencies[J].Phys. Fluids.1978, 21(12):2354-2364[15]Wang Q S, McDermott D B, and Luhmann N C. Operation of a stable 200-kW second harmonic gyro-TWT amplifier[J].IEEE Trans. on Plasma Sci.1996, 24(3):700-706[16]Luo Jirun, Zhang Shichang, Ding Yaogen, and Song Wenmiao. Design of a rotating mode filter. Proceedings of 24th International Conference on Millimeter Waves, Montery, California, USA, 1999: 391-394.
