苜蓿叶形耦合腔慢波结构的模拟和验证
doi: 10.3724/SP.J.1146.2005.01476
Simulation and Verification of Clover-Leaf Coupled Cavity Slow-Wave Structure
-
摘要: 苜蓿叶形耦合腔慢波结构是一种高耦合阻抗的慢波线。由于结构复杂，其数学分析及工程设计都非常困难。该文利用三维电磁计算软件Isfel3d，Mafia，HFSS对这种结构的色散特性、耦合阻抗进行数值模拟，在分析模拟结果的基础上，对这种结构做了初步的优化。结果表明，数值模拟与实验结果有很好的一致性，这对改进这种慢波线的工程设计具有重要意义。Abstract: Clover-leaf coupled cavity is a kind of slow-wave structure of high interaction impedance.The mathematic analyse and the engineering design are very difficult for its complex structure.In this paper, three- dimensional simulation codes Isfel3d，Mafia，HFSS are used to determine the dispersion and interaction impedance.Based on analyse of simulate results,the coupled cavity slow-wave structure is optimized primarily.The simulation results is consistent with the measurement results and is significant to design of the slow-wave structure.
-
Chodorow M and Craig R A. Some new circuits for high- power traveling-wave tubes[J].Proc.IRE.1957, 45(8):1106-[2]Chodorow M and Nalos E J. The design of high-power traveling-wave tubes[J].Proc.IRE.1956, 44(5):649-659[3]Lei W Q and Zhong H Y.Software cold test simulation of coupled cavity slow-wave structure in millimeter wave twt[J].International Journal of Infrared and Millimeter Waves.2003, 24(1):71-77[4]张国兴，戴卢富，刘准，等. MAFIA软件模拟三维耦合腔慢波结构. 电子学报，1997，25(6): 1-5.[5]张兆镗, 微波管高频系统的测量. 北京：国防工业出版社, 1982, 第四章.[6]刘盛纲. 微波电子学导论. 北京：国防工业出版社, 1985, 第十章. -
