紧凑型电磁带隙结构在短路微带天线中的应用
doi: 10.3724/SP.J.1146.2005.01418
Application of Compact Electromagnetic Band-Gap Structure to Shorted Micro-strip Antenna
-
摘要: 该文提出一种带有紧凑型电磁带隙结构的短路微带天线，并与相同尺寸的普通短路微带天线作比较。测试结果表明该电磁带隙结构天线在增益上增加了3dB， 面的交叉极化有了明显的改善。同时也证明了设计具有同样谐振频率的电磁带隙结构单元，使用这种紧凑型结构的单元边长尺寸仅为普通结构的5060％左右。这对最终实现电磁带隙结构微带相控阵天线具有重要意义。Abstract: A micro-strip shorted antenna with Compact Electromagnetic Band-Gap structure (CEBG) is presented. A shorted antenna with identical dimensions on a conventional ground plane is also included, so that a direct performance comparison can be made. Measured data shows a gain improvement of 3dB and a significant reduction in cross polarization for the CEBG antenna. Meanwhile it also proves that to design the same resonant frequency, the CEBG structure cell size is only about 5060% of conventional structure, and this is significant in realizing EBG micro-strip phased antenna array.
-
Yablonovitch E. Inhibited spontaneous emission in solid-state physics and electronics, Phys[J].Rev. Lett.1987, 58(20):2059-2062[2]Sievenpiper D F. High-impedance electromagnetic surfaces with a forbidden frequency band [J].IEEE Trans. on Microwave Theory Tech.1999, 47 (11):2059-2074[3]付云起，童创明等. 平面微波光子晶体的表面波带隙[J]. 国防科技大学学报，2002，25(2): 76-78.[4]付云起，袁乃昌等. 适合于电路集成的PBG结构微带线[J].国防科技大学学报，2001, 23(4): 120-122.[5]Gonzalo R G. Coupling between patch antennas on photonic crystals [J]. In Proc. 24th ESTEC Antenna Workshop, Noordwijk, The Netherlands, May 30-June 1, 2001: 6-10.[6]Iluz Z, Shavit R, and Bauer R. Micro-strip antenna phased array with electromagnetic band-gap substrate [J].IEEE Trans. on Antennas Propagat.2004, 52(4):1446-1453[7]Alley D. Interdigital capacitors and their applications to lumped-element microwave integrated circuits [J].IEEE Trans. on MTT.1970, 18(12):1028-1033[8]Coccoli R, Yang F, and Itoch T. Aperture-coupled patch antenna on UC-PBG substrate [J].IEEE Trans on Microwave Theory Tech.1999, 47(11):2123-2130 -
