一种基于枝切法和有限元法的干涉SAR合成相位展开方法
doi: 10.3724/SP.J.1146.2005.01119
A Phase Unwrapping Approach Based on the Branch-Cut Method and Finite Element Method for Interferometric SAR
-
摘要: 该文提出了一种基于枝切法和有限元法的干涉SAR相位图展开方法。该方法针对不同质量的相位区域采用不同的方法：首先利用枝切法准确性高和一致性好的特点，使用该方法展开面积最大的一块缠绕相位区域；然后在较好的边值条件下利用最小二乘意义下的有限元法求解剩余区域的展开相位。仿真和实测数据处理结果表明，该方法很好地克服了枝切法不能得到完整解和最小二乘法对于相位坡度欠估计的缺点，且与其它方法相比具有较高的精度。Abstract: A two-dimensional phase unwrapping approach is proposed using the branch-cut method and finite element method. Different strategies are taken for different quality data regions: first, using the congruence characteristic of the branch-cut method, the unwrapped phases can be retrieved in the reliable region with the largest area; then with good boundary values provided, the remaining regions are unwrapped with the finite element method (FEM) in a least square sense. Experimental results, carried out on simulated and real data, show that the proposed approach overcomes the drawbacks of the branch-cut method and FEM, i.e., the half-baked solution and phase slope underestimation, respectively, and has an advantage over other approaches in accuracy.
-
[1] Rosen P A, Hensley S, Joughin I R, Li F K, Madsen S N, Rodrguez E, and Goldstein R M. Synthetic aperture radar interferometry[J].Proc. IEEE.2000, 88(3):333-382 [2] Ghiglia D C and Pritt M D. Two-Dimensional Phase Unwrapping: Theory, Algorithms, and Software. New York: Wiley, 1998: 74-76. [3] Goldstein R M, Zebker H A, and Werner C L. Satellite radar interferometry: Two-dimensional phase unwrapping[J].Radio Science.1988, 23(4):713-720 [4] Xu W and Cumming I. A region growing algorithm for InSAR phase unwrapping[J].IEEE Trans. on Geosci. Remote Sensing.1999, 37(1):124-134 [5] Fornaro G and Sansosti E. A two-dimensional region growing least squares phase unwrapping algorithm for interferometric SAR processing[J].IEEE Trans. on Geosci. Remote Sensing.1999, 37(5):2215-2226 [6] Pritt M D and Shipman J S. Least-squares two-dimensional phase unwrapping using FFT[J].IEEE Trans. on Geosci. Remote Sensing.1994, 32(3):706-708 [7] Costantini M. A novel phase unwrapping method based on network programming. IEEE Trans. on Geosci. Remote Sens. 1998, 36(3): 813-821. [8] Bamler R, Adam N, Davidson G W, and Just D. Noise-induce slope distortion in 2-D phase unwrapping by linear estimators with application to SAR interferometry[J].IEEE Trans. on Geosci. Remote Sensing.1998, 36(3):913-921 [9] Kwon Y W and Bang H. The Finite Element Method Using MATLAB. New York: CRC, 2000: 85-86. [10] Lee J S, Hoppel K W, and Mango S A. Intensity and phase statistics of multilook polarimetric and interferometric SAR imagery[J].IEEE Trans. on Geosci Remote Sensing.1994, 32(5):1017-1027 -
