高速印刷电路板间垂直通孔的建模与分析

任志军; 孙玉发

doi:10.3724/SP.J.1146.2005.01049

高速印刷电路板间垂直通孔的建模与分析

doi: 10.3724/SP.J.1146.2005.01049

基金项目:

安徽省教育厅重点科研基金(2004kj002zd)资助课题

计量
- 文章访问数: 2949
- HTML全文浏览量: 92
- PDF下载量: 753
- 被引次数: 0
出版历程
- 收稿日期: 2005-08-23
- 修回日期: 2006-02-20
- 刊出日期: 2007-04-19

Modeling and Analysis of Vertical Vias in High Speed Printed Circuit Board

摘要

摘要: 通孔是现代高速印刷电路板中最常用的互连结构之一，其在传输信号特别是高速信号时会带来一系列信号完整性问题，因此对其进行准确、快速、有效的电磁建模与仿真将变得极为重要。该文使用一种基于Foldy-Lax方程的全波分析法并结合网络级联理论对其进行电磁建模。在单层垂直通孔结构中，建立柱体通孔间的Foldy-Lax多径散射方程，求得柱体通孔的激励场系数，计算出单层垂直通孔的散射矩阵，再应用多端口网络级联理论便可得到多层垂直通孔的散射矩阵。最后给出了四层垂直通孔散射参数的计算结果，并与已有文献结果进行了比较，两者吻合良好,从而验证了该方法的有效性。
- 通孔;垂直通孔;Foldy-Lax方程;多径散射;网络级联
Abstract: Vias are one of the most common interconnection structures used in modern high speed Printed Circuit Board (PCB), which would induce a series of problems such as loss of signal integrity when transmitting signal especially high speed signal. So it is very important that vias are modeled and simulated accurately, speedily, efficiently. The network cascade theory combined with a semi-analytical full wave approach based on Foldy-Lax equation is used to model vias in this paper. In single-layer vertical vias, the Fold-Lax equations of multiple scattering among the cylindrical vias are given. The exciting field coefficients of cylindrical vias are solved. The scattering matrix of coupling among single-layer vias is calculated. By multi-port network cascade theory, the scattering matrix of coupling among multi-layer vertical vias is obtained. The results of scattering matrix are given for 4-layer vertical vias, which show that the method presented in this paper is correct and valid.

HTML全文

参考文献(1)

[1] Wang T, Harrington R F, and Mautz J R. Quasi-static analysis of a microstrip via through a hole in a ground plane[J].IEEE Trans. on Microwave Theory Tech.1988, 36(6):1008-1013 [2] Kok P and De Zutter D. Capacitance of a circular symmetric model of a via hole including finite ground plane thickness[J].IEEE Trans. on Microwave Theory Tech.1991, 39(7):1229-1234 [3] Quine J P, Webster H F, Glascock H H, and Carlson R O. Characterization of via connections in silicon circuit boards[J].IEEE Trans. on Microwave Theory Tech.1988, 36(1):21-27 [4] Goldfarb M E and Pucel R A. Modeling via hole grounds in microstrip[J].IEEE Microwave and Guided Wave Lett.1988, 1(6):135-137 [5] Gu Q, Yang Y E, and Tassoudji M A. Modeling and analysis of vias in multi-layered integrated circuits[J].IEEE Trans. on Microwave Theory Tech.1993, 41(2):206-214 [6] Gu Q, Yang Y E, Poh S Y, Shin R T and Kong J A. Coupled noise analysis for adjacent vias in multilayered digital circuits[J]. IEEE Trans. on Circuits Syst., 1994, 41(12): 796-804. [7] Hsu S G and Wu R B. Full wave characterization of a through hole via using the matrix-penciled moment method[J].IEEE Trans. on Microwave Theory Tech.1994, 42(8):1540-1547 [8] Hsu S G and Wu R B. Full wave characterization of a through hole via in multi-layered packaging[J].IEEE Trans. on Microwave Theory Tech.1995, 43(5):1073-1081 [9] Tsang L, Chen H, Huang C, and Jandhyala V. Modeling of multiple scattering among vias in planar waveguide using Foldy-Lax equations[J].Microwave Opt. Technol. Lett.2001, 31(3):201-208 [10] Tsang L, Kong L, and Ding H K. Scattering of Electromagnetic Waves: Vol.1 Theory and Applications[M]. New York: Wiley Interscience, 2000: 83-91. [11] Tsang L, Kong J A, Ding H K, and Ao C. Scattering of Electromagnetic Waves: Vol.2 Numerical Simulations[M]. New York: Wiley Interscience, 2001: 469-485 622-639. [12] 阎润卿, 李英惠. 微波技术基础[M]. 北京: 北京理工大学出版社, 1988: 316-320.
