蚁群算法和Powell法结合的多分辨率三维图像配准

杨帆; 张汗灵

doi:10.3724/SP.J.1146.2005.01010

蚁群算法和Powell法结合的多分辨率三维图像配准

doi: 10.3724/SP.J.1146.2005.01010

杨帆,
张汗灵

基金项目:

湖南大学校基金(2004018)资助课题

计量
- 文章访问数: 3607
- HTML全文浏览量: 83
- PDF下载量: 1248
- 被引次数: 0
出版历程
- 收稿日期: 2005-08-16
- 修回日期: 2005-12-26
- 刊出日期: 2007-03-19

Multiresolution 3D Image Registration Using Hybrid Ant Colony Algorithm and Powells Method

摘要

摘要: 基于互信息的配准方法具有精度高，鲁棒性强的特点，成为近年来图像配准研究的热点。但基于互信息的目标函数存在许多局部极值，为配准的优化过程带来了很大的困难。该文提出了一种蚁群算法和Powell法相结合的多分辨率搜索优化算法。该算法以互信息作为相似性测度，采用基于小波变换的多分辨率策略，将蚁群算法与Powell法结合起来对三维的CT，MR图像进行了配准。实验结果表明，这种方法能够有效地克服互信息函数的局部极值，大大地提高了配准精度，达到亚像素级。
- 图像配准;互信息;蚁群算法;Powell法
Abstract: Image registration based on mutual information is of high accuracy and robustness. Hence, it has received much attention these years. Unfortunately, the mutual information function is generally not a smooth function but one containing many local maxima, which has a large influence on optimization. This paper proposes a registration method based on wavelet representation. In this method the mutual information is used as the similarity measure and a hybrid algorithm combined by ant colony algorithm and Powells method as the search technique. This method is applied to the 3D registration of CT and MR. Experiments shows that this registration method could efficiently restrain local maxima of mutual information function and the subvoxel accuracy can be achieved.

HTML全文

参考文献(1)

[1] Maes F, Collignon A, and Vandermeulen D, et al.. Multimodality image registration by maximization of mutual information[J].IEEE Trans. on Medical Imaging.1997, 16(2):187-198 [2] Maes F, Vandermeulen D, and Suetens P. Comparative evaluation of multiresolution optimization strategies for multimodality image registration by maximization of mutual information[J].Medical Image Analysis.1999, 3(4):373-386 [3] Pluim J P W, Maintz J B A, and Viergever M A. Mutual information based registration of medical images: A survey[J].IEEE Trans. on Medical Imaging.2003, 22(8):986-1004 [4] Plattard D, Soret M, and Troccaz J, et al.. Patient set-up using portal images: 2D/2D image registration using mutual information[J].Computer Aided Surgery.2000, 5(4):246-262 [5] Jenkinson M and Smith S. A global optimization method for robust affine registration of brain images[J].Medical Image Analysis.2001, 5(2):143-156 [6] Wachowiak M P, Smolikova R, and Zheng Y. An approach to multimodal biomedical image registration utilizing particle swarm optimization[J].IEEE Trans. on Evolutionary Computation.2004, 8(3):289-301 [7] Wachowiak M P. Similarity metrics and optimization for multimodal biomedical image registration. [Dissertation], University of Louisville, 2003. [8] Studholme C, Hill D L G, and Hawkes D J. An overlap invariant entropy measure of 3D medical image alignment[J].Pattern Recognition.1999, 32(1):71-86 [9] 杨虎, 马斌荣, 任海萍等. 基于互信息的人脑图像配准研究. 中国医学物理学杂志, 2001, 18(2): 69-73. Yang Hu, Ma Bin-rong, and Ren Hai-ping. Human brain image registration using mutual information. Chinese Journal of Medical Physics, 2001, 18(2): 69-73. [10] 马良. 来自昆虫世界的寻优策略蚂蚁算法. 自然杂志, 1999, 21(3): 161-163. Ma Liang. Ant algorithm─optimization strategy from the insect colony. Chinese Journal of Nature, 1999, 21(3): 161-163. [11] Dorigo M, Maniezzo V, and Colorni A. Ant system: Optimization by a colony of cooperating agents[J].IEEE Trans. on Systems, Man, and Cybernetic-Part B.1996, 26(1):29-41
